Pre Painted Galvanized Steel coil In coil

Product Description:

Pre Painted Galvanized Steel Coil

Thickness: 0.3-0.8mm

Width: 914-1250mm

Inner Diameter: 508mm，610MM

Weight of Steel Coil: 3-13MT

Available Dipped Layer: 50-150g/m²

Type of coating structure: 2/1 Coat the top surface of the steel sheet twice, coat the bottom surface once, and bake the sheet twice.

Front Side Paint Thickness: 15-25μm

Back Side Paint Thickness: 5-10μm

Pattern: can be customized according to customers requirements.

Suitable for indoor or outdoor decoration, color lasting for at least 10 years for outdoor using, could for roll forming.

1. Pre Painted Steel Coil is coated with organic layer, which provides higher anti-corrosion property and a longer lifespan than that of galvanized steel sheets.

2. The base metals for Pre Painted Steel Coil consist of cold rolled, HDG electro-galvanized and hot-dip alu-zinc coated steel. The finish coats of Pre Painted Steel Coil can be classified into groups as follows: polyester, silicon modified polyesters, polyvinylidene fluoride, high-durability polyester, etc.
