Polyvinyl Chloride (PVC) Waterproofing Membrane with UV Resistance

Loading Port:China main port

Payment Terms:TT OR LC

Min Order Qty:5000 m²

Supply Capability:100000 m²/month

Product Description:

Introduction

Polyvinyl chloride (PVC) waterproofing membrane is a macromolecule waterproofing membrane with superior performance. It is mainly made of polyvinyl chloride resin added with aid agents and aging resistance elements and produced by advanced plants and techniques. It has the characteristics such as superior tensile strength, good elongation, less shrink ratio, excellent low temperature flexibility and long lifetime.



PERFORMANCE INDEX

Performance indicators of Polyvinyl chloride waterproofing membrane

S/N

Items

Units

Indicators

H

L

P

G

GL

1

Thickness of resin coated on the central mat ≥

mm

-

0.4

2

Tensile property

Max. tensile force ≥

N/cm

-

120

250

-

120

Tensile strength≥

mpa

10.0

-

-

10.0

-

Elongation of max. tensile force≥

%

-

-

15

-

-

Elongation at break≥

%

200

150

-

200

100

3

Dimensional stability of hot treatment  ≤

%

2.0

1.0

0.5

0.1

0.1

4

Low temperature bending  -25°C

No crack

5

Water tightness 0.3kpa, 2h

Impermeable



PRODUCT FEATURES

Long lifetime and aging resistance. Lifetime of waterproofing membrane used on the roof is 20 years and that of waterproofing membrane underground.

Superior tensile strength, excellent elongation and less dimensional variation after hot treatment.

Superior low temperature flexibility and good performance suitable for environmental temperature change

Strong resistance to root puncture to be used for the roof

Excellent non-inflammability and self-quenching performance

Mildew resistance and efficient resistance to microbe damage

Easy installation, stable welding and friendly to environment

Strong chemical resistance and applied to special condition

Excellent modeling property and quick treatment to the corner

Convenient maintenance with low cost



RFQ

1. What is your MOQ?

--Our MOQ is 5000 m2

2. Can you provide sample?

--Yes, samples are in stock. we can offer free sample for you.

3. Do you offer OEM service?

--Yes, we can print customers’ logo on the packaging;

And the size and specification can be produced and design according to your demand.



Polyvinyl Chloride (PVC) Waterproofing Membrane with UV Resistance
