Polyurethane Insulation Foam Material for Discontinuous Sandwich Panel

Loading Port:Tianjin

Payment Terms:TT OR LC

Min Order Qty:1000 m²

Supply Capability:1000000 m²/month

Product Description:

Specifications

Rigid Blend Polyols for Discontinuous sandwich panels

Rigid Blend Polyol for Discontinuous  sandwich panel    DBC-402B

Product Introduction

DBC402B blend polyols is a compound which consists of polyether polyols, surfactants, catalysts, foaming agent and flame retardant in a special ratio. The foam has good thermal insulation property, light in weight, high compression strength and flame retardance and other advantages. It is widely used to produce sandwich plates, corrugated plates etc, which applies to make cold stores, cabinets, portable shelters and so on.

Physical Property

Appearance

Hydroxyl value                   mgKOH/g

Dynamic viscosity  (25°C)      mPa.S

Density    (20°C)              g/ml

Storage temperature                °C

Storage stability                   month

Light yellow transparent viscous liquid

320-400

250-350

1.10-1.16

10-25

6

Recommended Ratio

Raw materials

pbw

DBC-402B blend polyols

Isocyanate

100

100-105

Technology and Reactivity(the exact value varies depending on processing conditions)

items

Manual mixing

High temperature machine

Raw material temperature     °C

Moulding temperature    °C

Cream time    s

Gel time      s

Free density  kg/m3

20-25

35-45

30-50

120-200

23-26

20-25

35-45

20-30

70-150

23-26

Foam Performance

Moulding density

Closed-cell rate

Thermal conductivity(15°C)

Compression strength(perpendicular to the direction of rising)

Dimensional stability

24h  -20°C

24h  100°C

Flame retardant grade

GB 6343

GB 10799

GB 3399

GB/T 8813



GB/T 8811





GB/T8624

   ≥38kg/m3

≥90%

       ≤22mW/(m.K)

≥140kPa





≤1%

≤1.5%

Level B2

FAQ:

1,Could we change the panel size?

   Yes, we can product according to your requirement.

2, What is Minumum Production per day?

   4000m2 per day x 8 hours.
