Product Description
Specifications:
| Type of cell | Poly |
| Maximum power (Wp) | 270-310W |
| Maximum power voltage (V) | 37V |
| Maximum power current (A) | 8A |
| Open circuit voltage (V) | 44.6V |
| Short circuit current (A) | 8.5A |
| Number of cells (Pcs) | 72 |
| Size of module (mm) | 1950*992*45 |
| Maximum system voltage (V) | 1000 |
| Temperature coefficients of Isc (%) | + 0.1/ °C |
| Temperature coefficients of Voc (%) | -0.38/ °C |
| Temperature coefficients of Pm (%) | -0.47/ °C |
| Tolerance Wattage (e.g. +/-3%) | +/-3% |
| Surface Maximum Load Capacity | 60m/s(200kg/sq.m) |
| Weight per piece (kg) | 23kgs |
| Junction Box Type | 4mm2, Length:1000mm, TUV,using irrigation methods sealing glue |
| Connectors and Cables Type | MC4 |
| Output Cables (mm) | φ=4mm², L=900mm |
| Cell Efficiency (%) | ≥17.6% |
| Output tolerance (%) | +/-3% |
| Frame (Material, Corners, etc.) | Aluminum |
| Front Glass | 3.2mm high transmission, Low Iron, Tempered Glass |
| Warranty | 10Years products warranty and 25 years 80% of power |
| Standard Test Conditions | AM1.5 1000mW/cm2 25°C |
| FF (%) | 72% |
| Operating temperature ºC | -40 °C ~+85 °C |
Packaging:
2pcs/carton, 180pcs/20GP
Advantages
1.Long Service Life
2.High Efficiency Solar Cells
3.Special Aluminum Frame Design
4.High Transmission, Low Iron Tempered Glass
5.Advanced Cell Encapsulation
Solar Panel Application:
1. Solar power station, field operation some huge engineer construction;
2. Living house and home building;
3. Office building, factory and warehouse;
4. other industrial and commercial applications.
