Loading Port:Shanghai
Payment Terms:TT or LC
Min Order Qty:1000 watt
Supply Capability:200000 watt/month
TUV,MCS,CEC,IEC61215,IEC61730,CE,UL approved solar panels
Long life time: 25Years lifetime guarantee, 12years workshop warrany
| Product Description | |||
| Characteristics | Unit | SL6P54-250W | |
| Maximum Power (Pmax) | W | 250 | |
| Power Tolerance | W | (0,+5) | |
| Maximum Power Voltage (Vmp) | V | 30.7 | |
| Maximum Power Current (Imp) | A | 8.14 | |
| Open Circuit Voltage (Voc) | V | 37.9 | |
| Short Circuit Current (Isc) | A | 8.72 | |
| Module Efficiency (ηm) | % | 17.03 | |
| Dimension of module | mm | 1480*992*40mm(64.6*39.1*1.6inch) | |
| Pmax Temperature Coefficient | %/C | -0.44 | |
| Voc Temperature Coefficient | %/C | -0.32 | |
| Isc Temperature Coefficient | %/C | 0.44 | |
| Maximum System Voltage | VDC | 1000(TUV);600(UL) | |
| Maximum Series Fuse Rating | A | 15 | |
| Operating Temperature | C | -40~ +85 | |
| NOCT | C | 45±2 | |
| STC:1000W/m2.AM1.5 and 25C cell temperature, NOCT : Nominal Operating Cell Temperature | |||
| PV panel model | Size | Container Spec | Quantity |
| 240W-250W Poly solar panels | 1480*808*35mm | 20ft Container | 382pcs |
| 40HQ Container | 764pcs | ||
Product Characteristics & Functions:
1) Clean & Free Solar Energy powered, No commercial electronic consumption.
2) Once Pay, Benefit Long!
3) Cut off conventional monthly boring electricity bills.
4) No manual operation, No maintenance!
5) Value-Added, will pay itself back for you soon after one year.
6) High Quality, Prospective Innovation!
Long lifespan: 25Years lifetime guarantee, 12years workshop warranty. 90% output in first 10years. 85% output in next 15years.If module fail during warranty period, please contact local dealer, and provide the warranty card to replace the products.
Solar panels are withstand extreme working condition (from -40°C to 120°C)
Grade A solar panels rated by TUV.
High transformation efficiency solar panels
New UV reflector protected Layer
Maintenance free solar panels
No exposed metal parts
Custom-made available
100% EL TEST before and after laminator for each solar panels
TUV,MCS,CEC,IEC61215,IEC61730,CE,UL approved solar panels
CHUBB insurance company to guarantee the quality of solar panels
Bankable solar panels in German,Italy,UK,Denmark country
FAQ
We have organized several common questions for our clients，may help you sincerely：
①what price for each watt?
it depends on the quantity, delivery date and payment terms,
②what is your size for each module? can you tell me the parameter of your module?
we have different series of panels in different output, both c-si and a-si. please take the specification sheet for your reference.
③Can you provide the peripheral products of the solar panels, such as the battery, controller, and inverter? If so, can you tell me how do they match each other?
Yes, we can, we have two companies for solar region, one is CNBM International, the other is CNBM engineering Co.
We can provide you not only the solar module but also Solar Cells, the off grid solar system, we can also provide you service with on grid plant.
④What is your warranty system?
Our product performance guarantees for 25 years
• 12 years guarantee for workmanship
• Timeliness of delivery
• Quality Products certified (TÜV, UL, CE, ISO)
⑤How do you pack your products?
We have rich experience on how to pack the panels to make sure the safety on shipment when it arrives at the destination.
⑥ Can you do OEM for us?
Yes, we can.
⑦How long can we receive the product after purchase?
In the purchase of product within three working days, We will arrange the factory delivery as soon as possible. The pecific time of receiving is related to the state and position of customers. Commonly 7 to 10 working days can be served.
