P16 Outdoor Full Color LED Message Sign CMAX-P16

Product Description:

Specifications

1.High Brightness
2.Energy Saving
3.Water Proof
4.Certificate: CE,ROHS,CCC,FCC,ETL

60X140 pixels outdoor red led moving message sign
Display size: 960X2240mm
Case size: 1050X2330mm
Pitch: 16mm
Resolution: 60X140 pixels
Whole screen resolution: 8,400 pixels
Display color: RGB full color
Pixel composition: 1R1G1B per pixel
LED type: DIP346
Cabinet: iron, waterproof
Driver mode: static driver
Communication way: network port or rs232 or USB to communicate with PC
Include meanwell power supply, control system and wooden packaging
It can display text, number, graphics, time, temperature, video and movie etc.

2. Function

1) Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal, including CVBS, S-Video, VGA, DVI, HDMI.
2) 8 bits controller: 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade.
3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
4) Line-Double technology is adopted for the picture adjustment.
5) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL. (One-Sever-AnyClients supported)
6) Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof.
7) Calibration function supported.
