Loading Port:Shanghai
Payment Terms:TT or LC
Min Order Qty:10 unit
Supply Capability:100 unit/month
Description:
CNBM Solar is a world-leading and Vertical integrated manufacturer of high-performance with Silicon,
Wafer, Cells, Modules, which convert sunlight into electricity for residential, commercial, and utility-scale
power generation.
The capacity of CNBMSolar is reach to 1GW, and make sure each year our shipment capacity is more
Than 700-800MWs, at the same time, we have set up the largest solar power station with our partner
in Ukraine.
CNBM is a Quality + Service oriented company with“Excellence at Each Step” approach, composed of
the finest components from TUV and IEC-certified partners around the world, CNBM modules consistently
undergo a variety of trials at the company’s Test & Development Centre, ensuring peak performance
capabilities. The company is committed to develop and provide the world with clean and renewable energy
to ease the energy shortages as well as human kind’s impact on the environment.
Feature and data
GoodWe central GW500K-MTL solar inverter is widely used in large-scale solar power plants. As core equipment in solar power station, its stability and reliability play an important role in long-term investment returns. GW500K-MTL solar inverter adopts industrial design philosophy as well as proven inverter control technology, which ensures its 25 years life time. In terms of solar plants grid integration, GoodWe solar inverter is also equipped with output power liner control, SVG reactive power compensation technology, LVRT capability and other advanced technologies which are apt to grid integration and management. In addition, its lower THDi output and higher conversion efficiency provide stronger support to green and efficient power plants operation.
| DC Input Data | Max. PV-generator power [KW] | 550 |
| Max. DC voltage [V] | 1000 | |
Max. DC current [A] | 1200 | |
| MPPT voltage range [V] | 450~820 | |
| Max. input numbers | 10 | |
| Nighttime self-energy consumption [W] | <100< td=""> | |
| AC Output Data | Nominal output power [KW] | 500 |
| Nominal output voltage(Line Voltage) [V] | 270 | |
| Grid voltage range(Line Voltage) [V] | 310~450(Equipped with 270/400 tranformer) | |
| Rated output current [A] | 1070 | |
| Max. output current [A] | 1177 | |
| Nominal grid frequency [Hz] | 50/60 | |
| Grid frequency range [Hz] | 47.5~52.5/57~63 | |
| THDi | <1%< td=""> | |
| Efficiency | Max. efficiency | 98.8% |
| European efficiency | 98.6% | |
| MPPT adaptation efficiency | >99.5% | |
| Gerenal Data | Dimensions (WxHxD) [mm] | 2610*2165*800 |
| Net weight [kg] | 2100 | |
| Housing | Indoor | |
| Operating temperature range | -25～55℃ | |
| Relative humidity | 0 ~ 95% | |
| IP Protection class | IP20 | |
| Topology | Transformer electric isolation | |
| Cooling | Forced air-cooling | |
| Communication | RS485(Ethernet/GPRS Optional) | |
| Display | 7"LCD Touch Screen | |
| Standard Warranty [years] | 2 (Extention optional) |
FAQ:Pls introduce more about CNBM
CNBM is a China government leading company ,one of Fortune 500
