Item | Parameter |
Model | DGY24 |
Overall weight | 38.3MT |
Standard bucket capacity | 0.5m |
Rated power of engine | 198KW |
Rated rotation speed | 2000rpm |
Hydraulic system pressure | 34.3MPa |
Flow rate | 2*226L/min. |
Slewing speed | 11.7rpm |
Max. pulling force | 174KN |
Max. travel speed (H/L) | 5.2/3.5Km/h |
Grade-ability | 70° |
Bucket digging force | 52.7KN |
Average ground pressure | 61KPa |
Operating type | Hydraulic servo |
Overall length | 11903 mm |
Overall width | 3390 mm |
Overall height (top of boom) | 9340mm |
Overall height (top of operator's cab) | 3280mm |
Counter weight ground clearance | 1210mm |
Min. ground clearance | 598mm |
Turning radius at swing table tail | 4048mm |
Crawler ground length | 3700mm |
Crawler length | 4622mm |
Crawler gauge | 2590mm |
Crawler width | 3190mm |
Crawler shoes thickness | 800mm |
Swing table width | 2995mm |
Max. digging height | 13.4m |
Max. dumping clearance | 11300mm |
Max. digging depth | 6080mm |
Max. vertical digging depth | 5400mm |
Max. digging radius | 5800mm |
Max. height when Min. slewing radius | 9523mm |
Most suitable OD of pipe for hoisting | 1016mm |
Max. length of pipe for hoisting | 12m |
Max. rated lifting load | 24MT |
Boom length | 12.2m |
Counter weight height | 12000mm |
Crawler ground length (during transportation) | 4622mm |
Qty. of steel wire rope for hoisting | 6 |
Diameter of steel wire rope for hoisting | 14mm |
Max. lifting height | 11.8m |
