Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Motor Grade 190HPr Gr180 from China with CE
Model NO.:Gr180
Type:Motor Grader
Usage:Universal Type
Scraper Type:Pull Scraper
Transmission:Power Transmission
Walking Mode:Wheeled
Engine Power:147~515kw
Certification:ISO9001: 2000
Condition:New
Color:Yellow
Dimension(L*W*H):6690X2480X3330
Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:XCMG
Packing:Nude Packing.
Standard:Standard
Origin:China
Production Capacity:500 Sets / Month
CategoryItemsValue
Engine model: D6114ZG1B
Rated power/speed: 140/2200r/min
Overall dimension: 9298x2601x3430 mm
Operating weight: 15400 kg
Operating weight on front wheel: 4620 kg
Operating weight on rear wheel: 10780 kg
Tire: 17.5-25 RP12
Min. Grounding clearance: 430 mm
Clearance between front and rear axle: 6266 mm
Clearance between middle and rear wheel: 639 mm
Min. Turning radius: 7.8 m
Max. Lifting height of shovel: 460 mm
Max. Shoveling depth of shovel: 500 mm
Molboard widthxheight: 3965x610 mm
Forward speed: 5, 8, 11, 19, 23, 38 km/h
Rear speed: 5, 11, 23 km/h
Max. Traction force: 80 kN
Max. Climb ability: 20 %
Capacity of fuel tank: 280 L
Filling oil in engine: 24 L
Capacity of blance tank: 46 L
Filling oil in axle: 28 L
Hydraulic oil: 110 L
Turbochared tank: 2.5 L
Filling oil in transmission: 26 L
| Category | Items | Value |
| Engine model | D6114ZG1B | |
| Rated power/speed | km/h | 140/2200r/min |
| Overall dimension | mm | 9298x2601x3430 |
| Operating weight | kg | 15400 |
| Operating weight on front wheel | kg | 4620 |
| Operating weight on rear wheel | kg | 10780 |
| Tire | 17.5-25 RP12 | |
| Min. grounding clearance | mm | 430 |
| Clearance between front and rear axle | mm | 6266 |
| Clearance between middle and rear wheel | mm | 1639 |
| Max. steering angle on front wheel | % | 45(left and right) |
| Max. tipping angle on front wheel | % | 17 |
| Max. swing angle on front axle | % | 15 |
| Steering angle of frame | % | 25(left and right) |
| Min. turning radius | m | 7.8 |
| Max. lifting height of shovel | mm | 460 |
| Max. shoveling depth of shovel | mm | 500 |
| Max. side-dumping angle of shovel | % | 90 |
| cutting angle of shovel | % | 28-70 |
| Circle reversing rotation angle of shovel | % | 360 |
| Molboard widthxheight | mm | 3965x610 |
| Forward speed | km/h | 5, 8, 11, 19, 23, 38 |
| Rear speed | km/h | 5, 11, 23 |
| Max. traction force | kN | 80 |
| Max. climb ability | % | 20 |
| Pressure of tyre | bar | 2.6 |
| Pressure of working system | MPa | 18 |
| Pressure of transmission | MPa | 1.6-1.8(16-18kg/cm2) |
| Colding liquid | L | 50 |
| Capacity of fuel tank | L | 280 |
| Filling oil in engine | L | 24 |
| Capacity of blance tank | L | 46 |
| Filling oil in axle | L | 28 |
| Hydraulic oil | L | 110 |
| Turbochared tank | L | 2.5 |
| Filling oil in transmission | L | 26 |
