Loading Port:China main port
Payment Terms:TT or LC
Min Order Qty:1000 watt
Supply Capability:1000000 watt/month
| Place of Origin: | China (Mainland) | Brand Name: | CNBM | Model Number: | KPV200P-60 |
| Material: | Polycrystalline Silicon | Size: | 1650*992*50MM | Max. Power: | 250w |
| Weight: | 19.5KGS | Product: | monocrystalline solar panel 250w | Model No.: | kpv200p-60---250p-60 |
| Vmp: | 30.5V | Wp: | 200-250W | MSV: | 1000V DC |
| Pmpp: | -0.37%℃ | Isc: | +0.09%℃ | NOCT: | 47±2℃ |
| Size Of Cells: | 156*156MM |
1.High conversion efficiencies resulting in superior power output performance.
2.Outstanding power output even in low light or high temperature conditions
3.Optimized design for ease of soldering and lamination
4.Long-term stability,reliability and performance
| Packaging Detail: | 22 pieces of a case of Wooden case or other packaging |
| Delivery Detail: | 10 day |
monocrystalline solar panel 250w
High efficiency solar cells ensures high performance of solar module and create more power
250w Monocrystalline Solar Panel Pv Module With High Quality
Manufacturer
1. 3.2mm high transmissive Low iron tempered glass.EVA Iaminate with Glass yield long life modules while enhancing cell perfomance
2.Power range 200Wp-250Wp.
3.Pre-cables with fast-connecting system for convenient installation.
Quality and Safety
1.Rigorous quality control meeting the highest international standards
2.High-transmissivity low-iron tempered glass, strong aluminium frame
3.Using UV-resistant silicon
4.ISO 9001:2008 and ISO 14001:2004
5.IEC61215, IEC61730, Safety Class in conformity to CE
Warranties
1.25 years limited product warranty
2.15 years at 90% of the minimal rated power output
3.25 years at 80% of the minimal rated power output
Temperature Coefficient
| temperature coefficients | Pmmp | -0.37%/℃ |
| Voc | -0.34 %/℃ | |
| Isc | +0.09 %/℃ | |
| NOTC | 47±℃ |
| Module Size(mm) | 1650*992*50MM | ||||
| Module Array(pcs) | 6*10PCS | ||||
| Size Of Cells(mm) | 156*156MM | ||||
| Weight(kgs) | 19.5KGS | ||||
| Model No. | Power Rating (Wp) | Open Circuit Voltage(voc) | Open Circuit Current(ISC) | Maximum Power Voltage(VMP) | Maximum Power Current(IMP) |
| kpv200p-60 | 200W | 34.2V | 7.80A | 28.5 | 7.02A |
| kpv205p-60 | 205W | 34.2V | 7.80A | 28.5 | 7.19A |
| kpv210p-60 | 210W | 36.0V | 7.82A | 29.0 | 7.24A |
| kpv215p-60 | 215W | 36.0V | 8.01A | 29.0 | 7.41A |
| kpv220p-60 | 220W | 36.0V | 8.19A | 29.0 | 7.59A |
| kpv225p-60 | 225W | 36.6V | 8.24A | 29.5 | 7.63A |
| kpv230p-60 | 230W | 36.6V | 8.42A | 29.5 | 7.80A |
| kpv235p-60 | 235W | 37.2V | 8.46A | 30.0 | 7.83A |
| kpv240p-60 | 240W | 37.2V | 8.65A | 30.0 | 8.00A |
| kpv245p-60 | 245W | 37.2V | 8.74A | 30.0 | 8.17A |
| kpv250p-60 | 250W | 37.8V | 8.85A | 30.5 | 8.20A |
Module Dimension & Diagram
IV Carve
soler cell information
Payment Terms
T/T, L/C, Western Union, Paypal and Escrow are the payment methods we accept at present.
Shipping
Materials in stock can be produced (procedure 5-20days) right away after pre-payment confirmation. COSCO, Mearsk and MSC ship to worldwide for safe shipping, so don't worry about package damage or loss. It takes about 15-40 days to worldwide, Please note us your contact details, including your phone number, for easy contacting from shipping company officer.
Important Information
1. All our solar panels following IEC6125, IEC61730 standard, Have CE, TUV Certifications.
2. The solar cell efficiency is 16%-18.5%. All material certificates by TUV IEC test, meet the solar panel 25 years at outdoor performance.
