Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:1000 watt
Supply Capability:10000000 watt/month
Maximum power: 100Wp
Maximum working voltage: 18V
Maximum working current: 5.56A
Open circuit voltage: 21.60 V
Short-circuit current: 6.01 A
Cell number: 36 pcs
Cell dimensions: 125 x 125mm
Solar panel dimensions: 1,195 × 808 × 35mm
Maximum system voltage: 1,000V
Operating temperature: -40 to 85°C
Weight of each solar panel: 12kg
Connection box type: PV-JB001 (TUV)
Cable type: with TUV mark
Cable length: 900mm
Output power tolerance: ± 3%
Frame material: aluminum
Standard test conditions (STC): 1,000W/m² AM1.525°C
10 years product warranty and 25years 80% of power
Fill factor:72%
20-foot container quantity: 500pcs
40-foot container quantity: 1,000pcs
| Electrical Data | Module Size | Weight | Number of cells series | ||||
| Nominal Power | Max-Power | Max-Power | Open-Circuit | Short-Circuit | |||
| Voltage | Current | Voltage | Current | ||||
| Pmax | VMPP | IMPP | VOC | ISC | |||
| W | V | A | V | A | mm | Kg | pc |
| 120 | 17.2 | 6.98 | 21.6 | 7.72 | 1161*670*35 | 8.6 | 36 |
| 130 | 17.2 | 7.56 | 21.6 | 8.4 | 1277*670*35 | 9.8 | 36 |
| 140 | 17.2 | 4 | 21.6 | 4.4 | 1480*670*35 | 10.9 | 36 |
| 150 | 17.2 | 4.17 | 21.6 | 4.58 | 1480*670*35 | 10.9 | 36 |
| 160 | 34.4 | 4.65 | 43.2 | 5.17 | 1480*670*35 | 10.9 | 72 |
| 170 | 34.4 | 4.94 | 43.2 | 5.49 | 1172*983*35 | 11.7 | 72 |
| 180 | 34.4 | 5.23 | 43.2 | 5.81 | 1172*983*35 | 11.7 | 72 |
| 190 | 34.4 | 5.52 | 43.2 | 6.14 | 1260*983*35 | 14.6 | 72 |
| 200 | 34.4 | 5.81 | 43.2 | 6.5 | 1260*983*35 | 14.6 | 72 |
| 210 | 34.4 | 6.1 | 43.2 | 6.85 | 1488*983*35 | 14.6 | 72 |
| 220 | 34.4 | 6.4 | 43.2 | 7.08 | 1488*983*35 | 15.2 | 72 |
