Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
| Model | Unit | JCPT8 | JCPT9.5 | JCPT11.5 |
| Lift Rated Capacity | kg | 550 | 500 | 450 |
| Platform Extend Capacity | kg | 112 | ||
| Wind speed 45km/h | kg | 100 | ||
| Max. Machine Height | mm | 10000 | 11500 | 13500 |
| Max. Platform Height | mm | 8000 | 9500 | 11500 |
| Overall Length | mm | 3700 | ||
| Overall Width | mm | 1680 | ||
| Overall Height | mm | 2460 | 2580 | |
| Platform Size | mm | 2500X1120 | ||
| Platform Extend Length | mm | 1270X1120 | ||
| Ground Clearance | mm | 200 | ||
| Lifting Motor | 24VDC/2kw | |||
| Raising/falling speed | sec | 72/60 | 86/74 | 89/83 |
| Battery | 4x6V/210Ah | |||
| Charger | 24V/25A | |||
| Tyre(solid tire) | 6.50-10 | |||
| NW | kg | 2080 | 2090 | 2200 |
Standard Configuration
-Charge lamp
-High capacity traction battery
-Overload limit
-Extended platform
-Emergency stop button
-Emergency descending button
-Transport standard forklift hole
-Strut bar for safe overhaul
Optional Configuration
-AC power source connected to platform
-Rotary strobe light
