Loading Port:China main port
Payment Terms:TT OR LC
Min Order Qty:200 watt
Supply Capability:800000 watt/month
| Place of Origin: | Guangdong, China (Mainland) | Brand Name: | cnbm | Model Number: | CN40-PM |
| Type: | MCX | Approved: | TUV | Insulation material: | PPO |
| Contact material: | cooper , Ag plated | Rated current: | 30A | Rated voltage: | 1000V DC |
| Test voltage: | 6000V(50Hz,1min.) | Degree of protection: | 2 | Suitable cable: | 2.5-6.0mm2 |
| Temperature range: | -40℃~+125℃ | Life time: | 25years |
| Packaging Details: | 500sets/box size:40cm*26cm*29cm |
| Delivery Detail: | 3-7 working days |
MC4 panel connector
1,TUV approved
2,High current carrying capacity
3,Gender: male & female
4,Working life is 25 years
·Simple on-site processing
·Mating safety provided by keyed housings
·Mutiple plugging and unplugging cycles
·Accomodates PV cable with deferent insulation diamaters
·High current carrying capacity
·TUV approved
·Competive price
Technical data: | |||
Rated current : | 30A (2-6mm²) | Degree of protection: | IP2*/IP67 |
Retaed voltage: | 1000V DC | Flame class : | UL94-V0 |
Test voltage: | 6000V(50Hz,1min) | Safety class: | II |
Overvoltage category: | CATIII | Suitable class: | OD4.5-7.0(2.5-6.0mm²) |
Contact resistance of plug connector: | 1.0mΩ | Insertion force/withdrawal force: | ≤50N/≥50N |
Contact material: | Copper,silver Plated | Connecting System: | Crimp connection |
Insulation material : | PPO | Temperature range: | -40~+125 |
male
Order No. | Conductor size(mm²) | Panel cut size(mm) |
CN40-PMMM-14 | AWG 14(2.5mm²) | Ø12.0~12.5 |
CN40-PMMM-12 | AWG 12(4.0mm²) | |
| CN40-PMMM-10 | AWG 10(6.0mm²) |
female
Order No. | Conductor size(mm²) | Panel cut size(mm) |
CN40-PFPM-14 | AWG 14(2.5mm²) | Ø12.0~12.5 |
CN40-PFPM-12 | AWG 12(4.0mm²) | |
CN40-PFPM-10 | AWG 10(6.0mm²) |
