Loading Port:China main port
Payment Terms:TT OR LC
Min Order Qty:1 unit
Supply Capability:30 unit/month
Brief Description:
1, boom relief Angle is big, greatly widened the equipment capacity and scope of work.
2, suitable for the group of tower cross homework.
3, boom stability is good, combination amplitude range.
4, suitable for height have special requirements occasions construction.
5, lifting capacity big, effectively solve the high steel structure construction team crane big lifting capacity requirements.
Features:
Independent height (m) | 41.5 | ||||||
Max height with attachment (m) | 141.5 | ||||||
Working range can be adjusted(m) | 44/50 | ||||||
Min working range(m) | 2.5 | ||||||
Max lifting capacity(t) | 6 | ||||||
Tip load @ 48m(t) | 1.3 | ||||||
Hoist mechanism | Falls | 2 | 4 | ||||
Lifting capacity(t) | 1.5 | - | 3 | 3 | - | 6 | |
Speed(m/min) | 0 | - | 80 | 0 | - | 40 | |
Motor | YZRDWF225M-4/8-24/24KW | ||||||
Trolleying mechanism | Speed(m/min) | 12/27/53 | |||||
Motor | YZTDE132L-4 /8/16-3.3/2.2/1.1KW | ||||||
Slewing mechanism | Speed(r/min) | 0-0.6 | |||||
Motor | YZR132M2-6-3.7KW X2 | ||||||
Climbing speed(m/min) | 0.58 | ||||||
Counterweight(t) | 13.05 | ||||||
Mast section size(L×W×H)m | 1.6×1.6×2.5m | ||||||
Working temperature | -40-+60°C | ||||||
Total power (KW) | 37 | ||||||
Power supply requirement (KVA) | 180KVA for generator | ||||||
Cable type ( within 30 meters from site power source to lower electric box of tower crane ) | 50mm2(3+2, 5 cores) | ||||||
Startup voltage & current | 380V×95%=361V 285A | ||||||
Rated working voltage & current | 380V 108A
| ||||||
Loading Diagram:
FAQ
1. why chose us?
China National Building Materials (Group) Corporation (CNBM), established in 1984,now is one of the largest state-owned group corporation in China, dealing with building materials & industrial equipment. Up to year 2010, CNBM Group's total asset is 20 billion USD and total staff is more than 100,000.CNBM International Corporation, specializes in designing & manufacturing of various
kinds of construction machinery, including tower crane, building hoist, etc. All the equipment produced by CNBM are compliant with the National level quality standard, and wins great reputation for their endurable performance in worldwide markets.
2.How about the shipment?
You can put 2 sets of of wheel loaders in one 40HQ container. The spare parts are packed with boxes.
The delivery time is 20 days.
3. What about your service?
We have our factory, we can meet customers needs as soon as possible.
We have first rate professional technology and provide good after-sales service.
4.After Sales Service
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide. Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.
