Loading Port:Shenzhen
Payment Terms:L/C,T/T
Min Order Qty:1 Roll roll
Supply Capability:5000 Rolls Per Day roll/month
General Introduction
LED TYPE: 5630SMD
LED QTY:30leds/m 60leds/m
Chip Brand:Epistar Taiwan(14-15lm/LED)
Voltage:DC12V/24V
Power:7.2W/m 14.4W/m
Dimension:10*1000mm
Color:red/yellow/blue/green/white/pink/RGB
Ip grade:non-waterproof/IP65(epoxy resin)/IP67(silicone)
Lifespan:>50000H
Warrenty:2years(within 2years,our company will offer corresponding goods to repair or replace,once we confirm the badness of products are caused by our quality)
Specifications
| Part number | HKS-5630SMD60D-12V-WE |
| Input voltage | DC12V |
| Power | 14.4W/M |
| Beam angle | 120degree |
| Life span | 50.000-80.000hours |
| Certification | CE&ROHS |
| Rendering Index | >83Ra |
| Working temprature | -20°c~+50°c |
| Storage temprature | -30°c~+65°c |
| IP degree | IP67 |
| Frequency | 50-60HZ |
| Humidity | <85% |
| Power factory | >93% |
| Brightness | 300mcd |
| Lumen deline | <1% per 1000 hours |
| Dimensions | Width:10mm |
| LED QTY | Length:5meters/reel |
| 60LEDs/meter | |
300LEDs/reel | |
Available color |
Feature
Cutting every three LEDs along the cutting mark.
Back with 3M double tape.
More flexible,any bend angle.
IP 67 strip can be placed in the water completely,strong UV resistance.Wide application.
Package
5m/rees(the different length is available)
1reel/anti-static bag
40reels/inner-box
2inner-bag/carton carton size:46.5*30.6*42.2cm
Delivery:
Shipping Service | Estimated Delivery Time |
DHL | 2-8 business days |
FedEx | 3-8 business days |
TNT | 2-10 business days |
UPS | 1-7 business days |
EMS | 6-14 business days |
ePacket | 7-12 business days |
China Post Air Mail | 7-15 business days |
China Post SAL | 14-30 business days |
By Air | 3-10 business days |
By Sea | 30-40 business days |
Company profile
Our company is a professional LED products manufacture in China. Our products have been sold to Europe, America, Australia, Asia, and so on. Our products mainly include LED strips ( such as 1206 LED strips, 3528 LED strips, 5050 LED strips), LED tubes, LED spotlight, LED bulbs, LED modules, LED light, and so on.
