Loading Port:Qingdao Port
Payment Terms:TT or LC
Min Order Qty:25M.T. m.t.
Supply Capability:200000M.T./Year m.t./month
1. Chemical Elements of Low Chromium Alloyed Grinding Ball with Best Quality Rwa Material for Refractory Factory and Cement Plant
Name | Chemical Elements (%) | |||||||
C | Si | Mn | Cr | Mo | Cu | P | S | |
Medium Cr Balls | 2.2-3.3 | ≤1.2 | 0.5-1 | 4-6 | 0.6-1 | ≤1 | ≤0.05 | ≤0.05 |
2. Physical Property & Microstructure of Low Chromium Alloyed Grinding Ball with Best Quality Rwa Material for Refractory Factory and Cement Plant
Name | HRC | Ak(J/cm2) | Microstructure | Times of Falling Balls | |
Medium Cr Balls | ≥48 | ≥2.0 | P+C | ≤Φ80 | ≥15000 |
≥Φ80 | ≥10000 | ||||
3. Size & Weight of Low Chromium Alloyed Grinding Ball with Best Quality Rwa Material for Refractory Factory and Cement Plant
Size(mm) | Weight(kg/pc) | Quantity(pc/t) | Size(mm) | Weight(kg/pc) | Quantity(pc/t) | |
Φ30 | 0.11 | 9091 | Φ90 | 2.90 | 345 | |
Φ40 | 0.25 | 3891 | Φ100 | 4.00 | 250 | |
Φ50 | 0.50 | 2000 | Φ110 | 5.30 | 188 | |
Φ60 | 0.86 | 1153 | Φ120 | 6.80 | 147 | |
Φ70 | 1.37 | 729 | Φ130 | 7.70 | 129 | |
Φ80 | 2.05 | 487 | Φ140 | 8.74 | 114 |
