Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Loader High Cost Performance
Model NO.:SUNION GNHC75
Type:Skid Steer Loader
Walking Mode:Wheeled
Load and Unload Method:Front Discharge
Certification:CE, ISO9001: 2000
Condition:New
Operating Weight:3.5t
Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia
Trademark:SUNION
Packing:in Bulk or in Container
Standard:SGS
Origin:China
HS Code:3111968887
Production Capacity:100 Sets/Year
SUNION GNHC75 skid Steer Loader
Brand: SUNION
Model: GNHC75
Type: Wheel Loader
Condition: New
Standard: Excallent
Packing: In bulk or in container
Port: Shanghai
Delivery Time: Within 1 month
| Item | GNHC75 |
| Specifications | |
| Rated Load (kg) | 1050 |
| Tipping load (kg) | 2100 |
| Bucket capacity (m3) | 0.55-0.6 |
| Operationg weight (kg) | 3500 |
| Travel speed (km/h) | 12 |
| Hydraulic pump flow (L/min) | 75 |
| Fuel tank capacity (L) | 90 |
| Tyre model | 12/16.5NHS |
| Overall Size (mm) | 3560×1900×2050 |
| Dimensions | |
| Height at maximum extension (mm) | 4070 |
| The maximum pin shaft height (mm) | 3150 |
| Width with bucket (mm) | 1900 |
| Wheelbase (mm) | 1500 |
| Axles base (mm) | 1185 |
| ground clearance (mm) | 260 |
| Flip angle | 40° |
| Dumping height (mm) | 2450 |
| Approach angle | 26° |
| Departure angle | 20° |
| Engine | |
| Model | Xinchai498 |
| Rated power | 75hp/2500rpm |
| Displacement (L) | 3.3 |
