LED Encapsulant 5088A/B
1.Feature
5088A/B is a two components transparent liquid thermoset alicyclic epoxy resins which is developed for LED encapsulation. High Tg, long pot life, high temperature resistance and anti-UV light without yellowing. 5088A/B is wildly used in monochrome, RGB, or 3014, 3528, 5050 and other types of leadframe. The mixed (resin & hardener) viscosity can be adjusted within 600-10000 mPa S, in order to prevent different phospher from settling.
2.Typical Properties Before Curing
Item | Unit | Resin 5088A | Hardener 5088B | Remarks |
Component |
| Alicyclic Epoxy Resin | Acid Anhydride |
|
Color |
| Transparent | Transpatent |
|
Mixture Ratio | wt | 100 | 120 |
|
Density(25°C) | g/cm3 | 1.16 | 1.18 |
|
1.17(mixture) |
| |||
Viscosity(25°C) | mPa·S | 3000±1000 | 2000±1000 | Adjustable |
2500±1000(mixture) | Adjusted within 600-10000 | |||
Gel Time(120°C) | minute | 8±3 |
| |
PS: The above are representative of values, not specification value
3. Recommended IFU(Clean containers and tools before use. Introduction of foreign matter may affect performance of Encapsulant)
Step | Action | Caution |
1. preheating of resin | Clean the container before use, 100 aliquots of 5088A is preheated at 80°C for 40min. | Make sure container is clean |
2. Mixing | 120 aliquots of 5088B is added into 5088A, which is already preheated. Mix well with mixing propeller at 200rpm for 10-20 min. | A: B=100:120 (w/w) make sure proper mixing |
3. Defoaming | Vacuum machine with vacuum degree at -0.1MPa is used for 2-10min until bubbles are completely removed. | Make sure there is no bubble left |
4. Encapsulation | Use a dispenser to dispense. Clean the encapsulant left within the dispenser before use | Make sure there is no other foreign matter within the dispenser |
5. Initial Roast | Keep holder in the oven at 120°C for 1h | Make sure there is no other Encapsulant in the oven. Timing begins after oven temeperature reachs 120°C |
6. Long Time Roast | Keep holder (after initial roast) in the oven at 150 °C for another 2.5h | Make sure there is no other Encapsulant in the oven. Timing begins after oven temeperature reachs 150°C |
Notes: the mixture should be used within 10h after mixing. Viscosity would rise over time, which will influence performance. Call technical service if you have any questions.
4.Typical Properties After Curing
Item | Unit | Value | Remarks | |
Recommended Curing Conditions | 120°C×1h+150°C×2.5h | |||
Glass Transition(Tg) | °C | 158 | TMA | |
CTE | <Tg | ppm/°C | 65 | 40°C~80°C |
>Tg | 168 | 190°C~210°C | ||
Flexural Strength | N/mm2 | 95 | GB/T 2567-2008 | |
Flexural Modulus | N/mm2 | 3000 | GB/T 2567-2008 | |
Hardness(Shore D) |
| >85 | Shore D | |
Refractive Index |
| 1.50±0.01 | Abbe | |
Water Absorption | Wt% | 0.3 | 100°C/1hr | |
PS: The above are representative of values, not specification value
5.Packaging
5088A:1.0kg Fluoride Drum
5088B:1.2kg Fluoride Drum
6.Shelf Life
6 months under room temperature.
7.Safety
5088A may cause injury to skin following prolonged or repeated contact. Prevent prolonged or frequent contact. if contact occurs, wash at first opportunity with soap and water.
5088B may cause skin sensitization or other allergic responses. Avoid inhalation of vapor. Prevent all skin contact. If contact occurs, immediately with soap and water.
If you need to know about Safety and operating method of the detailed content, please refer to the MSDS (Material Safety Data Sheet)
