Lead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar Battery

Loading Port:Shanghai

Payment Terms:TT OR LC

Min Order Qty:1 pc

Supply Capability:100000 pc/month

Product Description:



Lead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar Battery







Product description



Lead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar BatteryLead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar Battery

Lead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar BatteryLead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar Battery

Lead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar BatteryLead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar Battery

Lead-Acid Battery AGM 12v 120ah 200ah 250ah 250 AH Solar Battery



12V Series Technical Data

1, Function Parameter

5, Environment Temperature

Norminal Voltage

12V

Discharge Temperature

-20-60℃

Norminal Capacity(10 hours rate)

250Ah

Charge Temperature

-10-50℃

6Numbers of Cells

6cell

Storage Temperature

-20-60℃

2, Rated Capacity at 25℃(77℉)

6, Inner Resistance & Max. Discharge Current

10hr,10.8V/cell,20℃/68℉

250Ah

Fully Charge Battery at 25℃(77℉)

2mΩ

3hr,10.8V/cell,20℃/68℉

191.7Ah

Max. Discharge Current

3750A(5s)

1hr,10.5V/cell,20℃/68℉

138.1Ah

Short Circuit Current

12500A

3, Capacity affected by Temperature(10 hour rate)

7, Self-discharge@25℃(77℉)

40℃(104℉)

103%

Capacity after 3 Month Storage

91%

25℃(77℉)

100%

Capacity after 6 Month Storage

82%

0℃(32℉)

85%

Capacity after 9 Month Storage

73%

-15℃(5℉)

65%

Capacity after 12 Month Storage

64%

4, Constant Voltage Charging at 25℃(77℉)

8, Dimension & Weight

Cycle Charge

14.4V~14.9V

Length

520mm

Maximum Charging Current

62.5A

Width

269mm

Temperature Compensation

-30mV/℃

Height

220mm

Float Charge

13.6-13.8V

Total Height

225mm

Temperature Compensation

-20mV/℃

Reference Weight

70kgs

Key Features :

♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like ,immobile and does not leak ,enabling
uniform reaction of each part of the plate .
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out , environment friendliness
♦Efficient venting system release excessive gas automatically

Applications :

♦EPS and UPS battery backup

♦Solar and wind energy storage system
♦Telecommunication Equipment
♦Power plant and transmission system

♦Signal system , emergency lighting system , security system





 FAQ

Q1: What is your terms of payment?A:  We accept T/T, L/C for big amount,PayPal, Western Union, Small-amount payment,



Q2: How's the delivery time ?
A:It will take about two weeks for production usually.



Q3: How about the standard of package?

A: For the small capacity, it use carton, but for big capacity, we should use strong wooden case

for protection.



Q4: Can you print my logo on the battery cover?
A: Yes, OEM is available,we can print your logo on the battery case, and you can offer your logo.



Q5: How to maintain the battery?
A:The battery should be stored in clean, dry, ventilated, dark environment when not using, keep it

after full charge, recharge it every 3 months or 6 months.



Q6: How can you tell if a battery is good or bad?
A: You should first check the battery for defects such as a broken circuit, a short, or a broken container.

If an outward problem is not apparent, then you will have to check the battery's capacity using known measuring techniques to ascertain the problem.



Q7: What kind of certificate you have ?

A. Our company already achieve ISO9001, and for products, we have CE, ROHS,SGS.
