Loading Port:China main port
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
LD180 Mini Crawler Excavator
LD180 Mini Crawler Excavatoris positioned on economical and practical and multifunction.Spare part are easy to maintenance, buy and replace.Compared with other brand excavator,Cheap in using and maintenance.Engine is 4 cylinder diesel engine provided power for digging.
| Packaging Details: | RoRo,on deck |
| Delivery Detail: | 4WEEKS |
China Famous Turbo Diesel Engine
Pressure & Flow Compensated System
Low Diesel Consumption
Digital Display Panel
Real-time Monitor of Machine Operating & Running
RANGE OF OPERATION | |
Boom Length | 3,610mm |
Maximum Digging Reach | 6,690mm |
Maximum Digging Depth | 4,195mm |
Maximum Digging Height | 6,295mm |
Maximum Dumping Height | 4,510mm |
Minimum Platform Tail Tuning Radius | 2,300mm |
DIMENSIONS | |
Width of Platform | 2,180mm |
Track Width | 450mm |
Machine Height | 2,640mm |
Distance from the Digging Arm to Rotate Machine | 4,210mm |
Maximum Length of transportation | 6,140mm |
THECHNICAL PERFORMANCE AND SPECIFCATION | |
Power | 60kW/2,200rpm |
Machine Weight | 6,000kg |
Volume of Bucket | 0.4m³ |
Set pressure with main spill valve | 25Mpa |
Maximum Digging Force | 50KN |
Grade ability | 35° |
Pressure to the Ground | 41.6kpa |
Travel Speed(High/Low) | 5.0/2.7km/h |
Maximum Traction Force | 40.6KN |
Swing Speed of Platform | 10.5rpm |
Fuel Tank Capacity | 190L |
Hydraulic Tank Capacity | 108L |
