Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
KMF 800 Manual Edge Banding Machine Characteristics:
It can finish the edge sealing work independently.
Machine can seal straight-edge, arc-edge.
The machine can be used for large-sized wooden boards and half-finished wooden products.
It can be automatic cut off sealing side.
Technical Datas
Model | KMF-800 |
Total Power | 1950W |
Tape Thickness | 0.3-3.0mm |
Width of Tape | 10-60mm |
Feeding Speed | 2-6m/min |
Glue Working Temperature | 200°C below |
Glue Pot Capacity | 620ML |
Machine Net Weight | 70KG |
Machine Size | 1000X870X1000mm |
Packing Size | 1000X850X600mm |
Technical Data :
Mini radius of banding : 20mm
Feeding speed : 2-6 meter/min
Thickness of banding :0.3-3.0mm
Width of banding tape:10-60mm
Working temperature : 200°C below
Motor Power : 25W
Total Power : 650W
Power supply : 220V/50-60HZ ,110V/50-60hz
Glue pot capacity :320ml
Net weight :9.2kg
Machine Size :410 x 370 x 450mm
Material of tape : PVC , Venner , melamine
