Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 m.t.
Supply Capability:10 m.t./month
| Application: | Heat Insulation | Thickness: | 10-100mm | Width: | 900/600mm |
| Length: | customized | Grade: | COM (Common) | Chemical Composition: | Aluminosilicate |
| Ultimate Strength (≥ MPa): | 0.04 | Working Temperature: | 950C | Fiber Diameter: | 3-5um |
| Thermal Conductivity: | 0.085-0.180w/m.k(400-100) | Shrinkage (1800℉, 3h): | -3 | Place of Origin: | Henan China (Mainland) |
| Model Number: | CT | Brand Name: | color: | white | |
| size: | can be customized | package: | plastic bag inside, braided bag outside | moisture: | 1% |
| theoretical density: | 280-320kg/m3 | item: | heat insulation ceramic fiber board |
| Packaging Detail: | plastic bag insiade, braided bag outside, or 2roll per carton. Or as your requires. |
| Delivery Detail: | 20 working days after receiving the earliest deposit |
Industry furnace used heat insulation ceramic fiber board
Product Description
Heat insulation ceramic fiber board views
Ceramic fiber board is the aluminum silicate fiber board, a kind of refractory material. Even after heating also keep good mechanical strength, has better heat insulation performace then ceramic fiber blanket and felt .
Heat insulation ceramic fiber board Advantage:
1. Low thermal conductivity ,heat storage and heat capacity
2. Excellent heat insulation
3. Excellent chemical stability
4. Shock and chemical attack resistant
5. Low thermal conductivity and shrinkage
6. Resilience under working condition, Low shrinkage under high temperature
7. Excellent sound insulation and resistance of folding
Application:
1. Industrial kiln observation hole, a thermometer inserted into the hole
2. industrial kiln burner stove
3. non-ferrous metals weld groove, groove gasket cap
4. Mechanical and electrical equipment connected gasket
Heat insulation ceramic fiber board Specification:
| ITEM | PRODUCT | COM | STD | HP | HA | HZ |
| Classification TemperatureºC | 1100 | 1260 | 1260 | 1360 | 1430 | |
| Working TemperatureºC | <1000 | 1000 | 1100 | 1200 | 1350 | |
| Color | white | white | white | white | white | |
| Densitykg/m3 | 96 128 | 96 128 | 96 128 | 128 160 | 128 160 | |
| Liner Shrinkage% After 24hours | -4 | -3 | -3 | -3 | -3 | |
| 1000ºC | 1000ºC | (1100ºC) | (1250ºC) | (1350ºC) | ||
| Thermal conductivityw/m.k density128Kg/m3) | 0.09 | 0.09 | 0.09 | 0.132 | 0.76 | |
| 400ºC | 400ºC | 400ºC | 600ºC | 600ºC | ||
| 0.176 | 0.176 | 0.176 | 0.22 | 0.22 | ||
| 800ºC | 800ºC | 800ºC | 1000ºC | 1000ºC | ||
| 0.22 | 0.28 | |||||
| 1000ºC | 1200ºC | |||||
| Tensile strengthMPa | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | |
| Size(mm) | Specification:7200X610X10-50,other according to customer's requirement | |||||
