Vehicle Model | ZZ1166SSMC46100 | ZZ1256SSNC43400 | ZZ1256SSNC46400 | |
Overall Dimension (Length × Width× Height) (mm) | 8106×2496×3000 | 9453×2496×3000 | 10080×2496×3000 | |
Gross Weight (kg) | 16000 | 25000 | 25000 | |
Dead Weight (kg) | 6950 | 8850 | 8900 | |
Max. Driving Speed (km/h) | 90 | 90 | 90 | |
Distance between Axles (mm) | 4600 | 4325+1350 | 4600+1350 | |
Engine | Model | WD615.97C | WD615.95C | WD615.95C |
Rated Power (kW/rpm) | 221/1900 | 249/1900 | 249/1900 | |
Max. Torque (N·m/rpm) | 1340/1200-1500 | 1490/1200-1500 | 1490/1200-1500 | |
Clutch | 430 diaphragm spring clutch | 430 diaphragm spring clutch | 430 diaphragm spring clutch | |
Gearbox | HW15710 | HW19710 | HW19710 | |
Drive Axle | ST16 single rear axle (i=4.8) | ST16 single rear axle (i=4.8) | ST16 single rear axle (i=4.8) | |
Steering Gear | ZF8098 | ZF8098 | ZF8098 | |
Braking Type | Service Braking | Dual-circuit, pneumatic braking | Dual-circuit, pneumatic braking | Dual-circuit, pneumatic braking |
Parking Braking | Manual braking, energy-storage spring type braking | Manual braking, energy-storage spring type braking | Manual braking, energy-storage spring type braking | |
Truck Cab | Steyr (King) four-door cab, 55° hydraulically tilting to the front | Steyr (King) four-door cab, 55° hydraulically tilting to the front | Steyr (King) four-door cab, 55° hydraulically tilting to the front | |
Electrical System | 24V, Negative earth | 24V, Negative earth | 24V, Negative earth | |
Tire | 11.00-20 | 11.00-20 | 11.00-20 | |
Oil Tank Capacity (L) | 200 | 200 | 200 | |
