Product description
Model NO.RYGH-HY30W | |
Wattage | 30W |
Voltage | DC 12V |
Certificate | CE, RoHs |
Luminance Flux | 130lm/w |
Power Factor | >0.95 |
Light Size | 650*220*200mm |
Solar Panel Size | 610*670*45mm |
Charge Time | 6 Hours with summer's sunshine |
Working Time | 3-4 rainy days, 12hours per night |
Lithium Battery | 12V/216WH |
Solar Panel | 18V/70W/mono |
Chip | SMD 3030 |
CRI: | >70 |
Color Temperature | 2700-6500K |
Beam Angle | 140*70° |
Mounting Height | 6m |
Function | Time sensor, Light sensor, Infrared sensors, remote control |
Mounting Distance | 30m for one-side road lighting,45m for both-side road lighting |
Working Temparature | -30℃~+60℃ |
Life Time | 50000 hours |
Warranty | 3 years |
MOQ | 1 PCS |
Specification:
1. Material:Aluminum + Steel glass
2. LED bead: 160LM per piece(CREE)
3. Mounting Height:7-8m
4. Lighting Time:3-4 rainy days, 12hours per night
5. Charge Time:6 Hours with summer's sunshine
6. Certificates:CE ROHS IP65 IES ISO standards 7. Function:Time sensor, Light sensor, Infrared sensors,Road indication light 8. Lighting Mode: The lamp works full night, for the first 1 hour of the night. When people pass by, the light is 100% powered on, lasting 20-30 seconds, and 30% when no people, for the second 3 hours of the night, the light is 80% on when people pass by, lasting 20-30 seconds , and 20% when no people. for the third 3 hours of the night, the light is 40% on when people pass by, lasting 20-30 seconds , and 10% when no people. for the forth 4 hours of the night, the light is 30% on when people pass by, lasting 20-30 seconds , and 10% when no people. for the last period till dawn, the light is 80% on when people pass by, lasting 20-30 seconds , and 30% when no people.
9. Mounting Distance:35m for one-side road lighting,60m for both-side road lighting
Advantages:
1, Our team has 13 years experience on LED Solar Street Light
2, Develop and manufacture light, solar panel,charge controller,battery independently
3, Complete production process and strict quality control
4, Major in 8W-120W All-in-one solar LED street light,Separated LED street light
5, Solar street light with Wifi,Bluetooth,APP(Android or IOS) remote control,motion sensor,camera and other functions
6, Pass CE/RoHS/ISO/IK08/CQC/COC Certificates
7, Bridgelux LED, 130-150lm/w for whole lamp
8, 3-5 years warranty
Production:
FAQ
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
A: Low MOQ, 1pc for sample checking is available
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A: Yes, we offer 2-5 years warranty to our products.
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
