General Introduction
(A) Name:LED WiFi Controller
(B) Model: 3 different design with different Function
(C) Product Summarize:
Welcome to use LED WiFi Controller, this controller is designed for LED strip, module etc. After easy installation and settings, you can use you Phone (IOS or Android system) to control the light. The remote control distance reach 50 meters indoor and more than 100 meters outdoor.
(D) Product constitute
NO. | Item | Description |
1 | LED WiFi Controller | It is the core of product, responsible for receive control signal and control LED equipment. |
2 | CD | Include mobile soft for IOS operating system and Android operating system. Product manual. |
3 | Wireless router(buy it own) | If you want to use online, suggest to connect wireless router(>150M) |
a) Item version:Single color version,Color temperature version and RGB version
b) Working Voltage: DC7.5-24V
c) Output channel: Can be used 3/2/1 channel
d) Output current: 4A*3 or 4A*2
e) Connecting method: Common anode
f) Dimension: L105.5*W45*H23mm Remote distance: 50 meters indoor, 100 meters outdoor
g) Software: Android system (at least version 2.3 with WIFI function) or IOS system,
h) Language : English/Chinese/German
i) Receiver sensitivity: 802.11b DSSS(-5dBm),802.11b CCK (-10dBm),802.11g OFDM(-15dBm)
j) Connect way: V+ R, G, B for LED Light, V+, V- for Power supply, ANT for WIFI signal reception.
k) Reset button(inside the controller): Short press: change from gradual change to strobe flash for single color Version. Or change in 27 modes for RGB Version.
l) Long press(more than 20s): Restore to factory settings. WiFi SSID for connection is “LEDnetXXXXXXXXXX”, password: “88888888”. IP: 192.168.10.1
l Android Software:
Name | LED Magic Color |
Running OS | Android 2.3 or above,request device have WiFi function |
Install App | Visit “Google Play”,search “ LED Magic Color”,then download and install it. |
Software Size | 1.1M |
Language | Chinese/English /Germany, automatic recognize language according to OS. |
l IOS Software:
Name | LED Magic Color |
Running OS | IOS5.0 or above,such as iPhone, iPad, and iPod touch device. |
Install App | Visit App Store,search”LED Magic Color”, then download and install it |
Software Size | 2.1 MB |
Language | Chinese/English /Germany, automatic recognize language according to OS. |
Category | communication |
