Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:10000 g/m²
Supply Capability:10000000 g/m²/month
Specifications
1.Fiberglass mesh size: 4X4 5X5 10X10 2X2 etc
2.Roll size:1x20m,50m-300m
3.Weight: 60-300g
4.High strength&many color choi
Specifications
1.Alkali resistant fiberglass mesh size: 2X2mm- 10X10mm etc
2.Roll size:1x20m,50m-300m
3.Weight:60g-300g
4.High strength
1.Performance
Our fiberglass mesh have good grid fixity, and high strength, good adhesion with cement mortar, excellent fitting positioning, excellent alkali resistance is very prominent, resistant to high alkaline substances concrete erosion. Strength retention rate> 90%, elongation <1%, the durability of more than 50 years. High elastic modulus 80.4Gpa, is can't reach by other chemical fibers.
2.Specifications
1) The size of our alkali resistant fiberglass mesh : 2X2mm 4X4mm 5X5mm 10X10mm etc .
2)The weight of our alkali resistant fiberglass mesh :60g,75g,100g,145g,165g etc .
3) We can produce many specifications and use different packagings according to customers' requests.
3.Technical date sheet
Item Number | Yarm (tex) | Mesh Size | Density Count/625px | Finished Weight(g/m2) | Tensile StrengthX500px | Woven Structure | Content of resin% (≥) | ||||
Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | ||||
TP5x5-70 | 45x2 | 200 | 5 | 5 | 5 | 5 | 70 | 550 | 850 | Leno | 16 |
TP5x5-80 | 67x2 | 200 | 5 | 5 | 5 | 5 | 80 | 700 | 850 | Leno | 16 |
TP5x5-90 | 67x2 | 250 | 5 | 5 | 5 | 5 | 90 | 700 | 1050 | Leno | 16 |
TP5x5-110 | 100x2 | 250 | 5 | 5 | 5 | 5 | 110 | 800 | 1050 | Leno | 16 |
TP5x5-125 | 134x2 | 250 | 5 | 5 | 5 | 5 | 125 | 1200 | 1300 | Leno | 16 |
TP5x5-135 | 134x2 | 300 | 5 | 5 | 5 | 5 | 135 | 1300 | 1400 | Leno | 16 |
TP4x4-135 | 100x2 | 250 | 4 | 4 | 6 | 6 | 135 | 1000 | 1300 | Leno | 16 |
TP5x5-145 | 134x2 | 360 | 5 | 5 | 5 | 5 | 145 | 1200 | 1300 | Leno | 16 |
TP4x5-150 | 134x2 | 300 | 4 | 5 | 6 | 5 | 150 | 1300 | 1300 | Leno | 16 |
TP5x5-160 | 134x2 | 400 | 5 | 5 | 5 | 5 | 160 | 1450 | 1600 | Leno | 16 |
TP4x4-160 | 134x2 | 300 | 4 | 4 | 6 | 6 | 160 | 1550 | 1650 | Leno | 16 |
TP4x5-165 | 134x2 | 350 | 4 | 5 | 6 | 5 | 165 | 1300 | 1300 | Leno | 16 |
