Home Storage Lithium Ion Batteries Battery 12V 50Ah for solar systems
Product Description
12V 50Ah Lithium Technical Data
Function Parameter | |||
Norminal Battery Energy | 640Wh | ||
Norminal Capacity | 50Ah | ||
Norminal Voltage | 12.8V | ||
Internal Resistance | ≤30mΩ | ||
Cycle Life | >2000 cycles @ 1C 100% DOD | ||
Months Self Discharge | <3% | ||
Charge Data | |||
Limited Charge Voltage | 14.6±0.1V | ||
Floating Charge Voltage | 13.8±0.2V | ||
Standard Charge Current | 25A | ||
Max. Charge Current | 50A | ||
Discharge Data | |||
Continuous Current | 25A | ||
Max Discharge current | 50A | ||
Pulse Discharge Current | Withstand the 100A/2s | ||
Discharge Cut-off Voltage | 8.0V | ||
Working Condition | |||
Charge Temperature | 0℃ to 45℃ (32℉ to 113℉) Relative Humidity | ||
Discharge Temperature | -20℃ to 60℃ (-4℉ to 140℉) Relative Humidity | ||
Operating Temperature: | 15℃ to 40℃ (35℉ to 95℉) Relative Humidity | ||
Mechanical Data | |||
Plastic Case | ABS | ||
Dimensions | 196*165*174mm | ||
Weight (lbs./kg.) | 7.00kgs (15.43lbs) | ||
Terminal | M6 | ||
Application
FAQ
1.Manufacturer or trading company?
CNBM is a manufacturer who focuses on Lithium battery business, including researching, manufacturing and applications. Products include LFP Li-battery, NCM Li-batteryand other battery system.
2.How can I pay for the goods?
You can pay by bank transfer. This means you pay from your bank to our bank account. This is the most favorite payment method. In European Union, please ask in your bank about the SEPA payment.
3.Can I have samples to test? And what is lead time for sample order
Yes, we can supply samples, the lead time for samples is 3-5 days.
4.Do you accept OEM/ODM?
Yes, it is available.
