Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
3000w home solar power system/stand alone solar power system
1.10W7AH solar energy kit
1.Attachments:1x3W/12V LED Bulb*2, Phon
| Solar Panel | |||||||
| Type | T2-160W |
| |||||
| Rated Maximum Power | 160W | ||||||
| Maximum Power Voltage (Vmp) | 36V | ||||||
| Maximum Power Current (Imp) | 4.44 | ||||||
| Open Circuit Voltage(Voc) | 42.48V | ||||||
| Short Circuit Current(Isc) | 4.89 | ||||||
| Power Toerance | ±3% | ||||||
| Maximum System Voltage | 1000V | ||||||
| Operating Temperature | -40℃~+85℃ | ||||||
| Standard Test Conditions | AM1.5 100mW/cm2 25’C | ||||||
| Size | 1580*808*35MM | ||||||
| Weight | 16.5KG | ||||||
| Quantity | 8PCS | ||||||
| Controller | |||||||
| System voltage | 48V | Balance charge voltage | 58.4V±1% | ||||
| System current | 30A | Increase charge voltage | 57.6V±1% |
| |||
| No-load loss | <15mA | Discharge protection voltage | 44.4V±1% | ||||
| Solar energy input voltage | <100V | Discharge protection voltage | 51.2V±1% | ||||
| Over voltage protection | 66V | Work temperature | -25℃to+60℃ | ||||
| Over voltage recovery | 60V | temperature | -4.0mv/℃/2V | ||||
| Over-load, short circuit protection | 1.25 times rating current 30S;1.5 times rating current 10S overload current protection;≥3 times rating current short circuit protection | ||||||
| Inverter | |||||||
| Rated power | 3000W | ||||||
| AC input | Voltage | 140V-275VAC | |||||
| Input Frequency | 40~60Hz | ||||||
| Charge current | ≤10A | ||||||
| DC voltage range allowed | 48V | ||||||
| AC output | Voltage | 110V/220/230/240VAC±5% | |||||
| Frequency | 50/60HZ±0.5 | ||||||
| Wave from | Sine-wave | ||||||
| Inverter efficiency | 80-90% | ||||||
| Work environment | Working temperature | -25℃~+50℃ | |||||
| Relative humidity | <90%,no condensing | ||||||
| Altitude | <1 500m | ||||||
| noise | ≤40dB | ||||||
| Protection | Battery under-voltage protection, battery over-voltage protection, output overload protection, over-current protection, Overload 150%, 10 seconds | ||||||
| power box | 600*490*470 | ||||||
| Weight | 47kg | ||||||
| Battery |  | ||||||
| Nominal capacity | 120AH | ||||||
| Dimensions | 409*174*240mm | ||||||
| Weight Approx | 34kg | ||||||
| Quantity | 8pcs | ||||||
| Accessories |    | ||||||
| PV module mounting system | 3000*150*150*1set Weight:36KG | ||||||
| cables | 80M Weight:6.4KG | ||||||
| battery box | size:750*580*180 15KG | ||||||
| User manual | 1pcs | ||||||
