Loading Port:Qingdao
Payment Terms:TT or LC
Min Order Qty:20000 m²
Supply Capability:200000 m²/month
High Strength PP Woven Geotextile
1. Description of High Strength PP Woven Geotextile
CMAX polypropylene woven geotextile is made from polypropylene flit yarn on circle weave machine, including circular loom and flat loom.
2. Specification of High Strength PP Woven Geotextile
Weight: 90gsm – 400gsm;
Width: 1m – 6m; Length: as clients’ required.
3. Technical Data Sheet of High Strength PP Woven Geotextile
Item | Unit | Index | ||||||
Unit Weight | g/m2 | 120 | 160 | 200 | 240 | 280 | 340 | 400 |
Breaking Strength in MD | KN/m | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
Breaking Strength in CD | KN/m | 15 | 22 | 28 | 35 | 42 | 56 | 70 |
Elongation Rate | % | 25 | ||||||
Trapezoidal Tearing Strength | KN | 0.2 | 0.27 | 0.34 | 0.41 | 0.48 | 0.6 | 0.72 |
CBR Mullen Burst Strength | KN | 1.6 | 2.4 | 3.2 | 4.0 | 4.8 | 6.0 | 7.5 |
Vertical Permeability | Cm/s | 10^-1 ~10^-4 | ||||||
Sieve Size O90(O95) | Mm | 0.07 ~ 0.50 | ||||||
Variation | % | ±10 | ||||||
4. Property of High Strength PP Woven Geotextile:
1).Light weight, high strength, low elongation, easy to construct.
2).Reinforcement, separation, drainage and filtration, fencing function.
5. Application of High Strength PP Woven Geotextile
Railways, highways, sport fields, earthwork projects, tunnels, coal mines, walls and slopes, environmental protection and so on.
.
High Strength PET Woven Geotextile
1. Description of PET Woven Geotextile
CMAX filament woven geotextile is made from polypropylene, high strength industrial synthetic fiber as the raw material, made through weaving technology.
2. Specification of PET Woven Geotextile
Breaking strength in MD(KN/m): 35, 50, 65, 80, 100, 120, 140, 160, 180, 200, 250;
Width: 1m – 6m.
3. Technical Data Sheet of PET Woven Geotextile
Item | Specification | ||||||||||
Material | Polyester | ||||||||||
MD(KN/m) | 35 | 50 | 65 | 80 | 100 | 120 | 140 | 160 | 180 | 200 | 250 |
CD(KN/m) | 35 | 50 | 65 | 80 | 100 | 120 | 140 | 160 | 180 | 200 | 250 |
Elongation at Break | MD=35; CD=30 | ||||||||||
Width Variation, % | ±0.1 | ||||||||||
CBR Mullen Burst Strength, KN | 2.0 | 4.0 | 6.0 | 8.0 | 10.5 | 13 | 15.5 | 18 | 20.5 | 23 | 28 |
Sieve Size O90(O95) mm | 0.07 ~ 0.50 | ||||||||||
Tearing Strength, KN | 0.5 | 00.8 | 1.1 | 1.3 | 1.5 | 1.7 | 1.9 | 2.1 | 2.3 | 2.5 | 3.0 |
Weight, g/m2 | 140 | 2200 | 260 | 320 | 390 | 450 | 530 | 600 | 680 | 760 | 950 |
Property of PET Woven Geotextile:
1) High strength, low deformation.
2) Durability: steady property, not easy to resolved, air slaked and can keep the original property long term.
3) Anti-erosion: anti-acid, anti-alkali, resists insects and mould.
4) Permeability: could control the sieve size to retain certain permeability.
Application of PET Woven Geotextile
It is widely used in river, coast, harbor, highway,railway, wharf, tunnel, bridge and other geotechnical engineering.
It could meet all kinds of geotechnical projects needs such as filtration, separation, reinforcement, protection and so on.
FAQ:
Questions and Answers:
Q: Can you accept sample order?
A: Yes, we accept samples with little and reasonable charge.
Q: What is your MOQ?
A: Normally, 5000 m2 per order.
Q: What is your delivery time? Can we short it in 7 days or less?
A: 7 days for sample, 20-25 days for mass production.
Q:How about your quality?
A: Try a small order, you will have your own judgment!
