Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:10 m.t.
Supply Capability:100 m.t./month
| Place of Origin: | Type: | Ceramic Parts | Application: | Structure Ceramic | |
| Material: | Zirconia Ceramic, zirconia ceramic | Model Number: | AV-zirconia ceramic structure | Brand Name: | AV |
| delivery time: | 30-45working days | characteristic: | high hardness/Anticorrosion/high temperature resistance | Surface: | Good Polished |
| Used in: | Textile industrial | life time: | Long service life | MOQ:: | 1Pcs |
| Payment terms: | 100%TT in advance |
| Packaging Detail: | Standard export packing |
| Delivery Detail: | 30-45days after receiving your payment |
Manufacture of zirconia ceramic structure
Anticorrosion and eco-friendly
temperature resistance
Best price with good quality
Zirconia ceramic struction/Zirconia ceramic rod/aluminium ceramic struction
1)Ultra low wear loss as a result of the transformation-toughening mechanism unique to the yttrium stabilited zirconia(YST) material system
2)Higher grinding efficiency and reduced grinding time due to the higher density of zirconia (compared with alumina and glass)
3)Most durable grinding material, reducing operational cost in the long run. Wear rate substantially lower than Al2O3, CeO2-ZrO2, and MgO-ZrO2 grinding media.
4)Suitable for high velocity operations and wet grinding operations.
Technical Specifications:
Property | Unit | Parameter |
Content | wt% | 94.6% ZrO2 5.2%Y2O3 |
Packing density | kg/L | 3.5 (Dia5mm) |
Density | g/cm3 | 6.00 |
Hardness(HV) | GPa | >12 |
Elastic modulis | GPa | 200 |
Thermal conductivity | W/m.K | 3 |
thermal Expansion coefficient | 10×10-6/°C (20 to 400) | 9.6 |
Pressing intensity | KN | ≥25(Dia5mm) |
Fracture tenacity | MPam½ | 8 |
Grain size | µm | ≤0.5 |
Specification Available:
Ball:Dia0.8,Dia1.0,Dia1.2,Dia1.4,Dia1.6,Dia1.8,Dia2,Dia3,Dia5,Dia6.5,Dia7,Dia8.5,Dia10,Dia12,Dia15,Dia20,Dia25,Dia30,Dia35mm ect;
Cylinder:Dia5×5,Dia7×7,Dia10×10,Dia12.7×12.7,Dia15×15,Dia20×20mm, ect.
Applications:
1, For grinding wear-resistant, corrosion-resistant products: paints, textiles, paints, printing and dyeing
2, For grinding high strength, high toughness products: magnetic materials, piezoelectric ceramics, dielectric ceramics
3,To prevent pollution: medicine, food, cosmetics
4, Ceramics: Electronic ceramics, refractory ceramics, structural ceramics
