Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:100 watt
Supply Capability:10000 watt/month
230W/36V solar panel/module for off grid solar system.
Poly cell source: Top brand;
Welcome any customer design.
Mechanical Characteristics:
Dimensions: 1956mm(L) x 992mm(W) x 35mm(H)
Weight: 24kg
Polycrystalline solar cells: 72 cells
Aluminum frame: High quality withstand strong wind and heavy snow, anti-corrosion.
Construction: Front: High-transmission 3.2mm tempered glass;
Encapsulate: EVA
TPT- COVEME Italy brand to ensure good quality.
Junction box: UL-certified
Module Warranty:
Warranty on material and workmanship: Five years
Guaranteed output of 90% after 10 years and 80% after 25 years.
| Performance | ||
| Rated Power[Pmax] | 230W | |
| Power Tolerance | ± 3% | |
| Nominal Voltage | 36V | |
| Design Life | 25 years | |
| Electrical Characteristics | ||
| Maximum Power [Pmax] | 230W± 5% | |
| Maximum Power Voltage [Vmp] | 34V± 3% | |
| Maximum Power Current [Imp] | 6.68A± 3% | |
| Short-Circuit Current [Isc] | 7.422A± 3% | |
| Open-Circuit Voltage [Voc] | 43.05V± 3% | |
| Current Temperature Coefficient | 0.08%/º C | |
| Voltage Temperature Coefficient | - 0.32%/º C | |
| Power Temperature Coefficient | -0.38%/º C | |
| Maximum System Voltage | 1000V | |
