Used Grid Connected Solar Inverter 4000-6000UE

Loading Port:Shekou

Payment Terms:TT or LC

Min Order Qty:10 pc

Supply Capability:10000 pc/month

Product Description:

Grid Connected Solar Inverter 4000-6000UE

Tri-power excellent inverter for small residential and commercial projects

DC input voltage up to 800V

Maximum efficiency of 97.9%

Internal DC switch

Transformerless

Compact design

Multi MPP controller

MTL-string

Bluetooth/ RF technology/ WiFi

Sound control

Easy installation

Grid Connected Solar Inverter 4000-6000UE

4000UE	5000UE	6000UE
Inputdata
Max.DCpower	4200W	5200W	6300W
Max. DC voltage	800V	800V	800V
Start Voltage	150V	150V	150V
PV voltage range	140V-800V	140V-800V	140V-800V
MPP voltage range /Nominal voltage	200V-800V/ 580V	200V-800V/ 580V	200V-800V/ 580V
Full load DC voltage range	250V-750V	300V-750V	350V-750V
Max. input current / per string	9A/9A	9A/9A	10A/10A
Number of independent MPP trackers/strings per MPP tracker	2/1	2/1	2/1

Output (AC)

Rated AC output power	4000W	5000W	6000W
Max. AC apparent power	4000VA	5000VA	6000VA
Max. output current	6.4A	7.9A	9.3A
Max. short-circuit current	20A	20A	20A
AC nominal voltage ;range	230/400V;184-275V	230/400V;184-275V	230/400V;184-275V
AC grid frequency; range	50Hz,60Hz; ±5Hz	50Hz,60Hz; ±5Hz	50Hz,60Hz; ±5Hz
Displacement power factor configurable	0.9leading-0.9lagging	0.9leading-0.9lagging	0.9leading-0.9lagging
THDI	＜3%	＜3%	＜3%
Grid connection type	3/N/PE,3W+PE(opt)	3/N/PE,3W+PE(opt)	3/N/PE,3W+PE(opt)

Efficiency

Max.efficiency
Euro-eta
MPPT efficiency

97%
95.1%
99.5%

97.4%
96.3%
99.5%

97.5%
96.5%
99.5%

Features

DC connection

AC connection

Display
Interface:RS232/RS485/
Bluetooth/RF/WiFi
Warranty: 5years/10years

H4/MC4(opt)

Screw terminal

LCD
yes/yes/

opt/opt/opt
yes/opt

H4/MC4(opt)

Screw terminal

LCD

yes/yes/

opt/opt/opt

yes/opt

H4/MC4(opt)

Screw terminal

LCD

yes/yes/

opt/opt/opt

yes/opt

Generaldata

Dimensions(W/H/D) in mm
Weight
Operating temperature range
Noise emission(typical)
Self consumption (night)
Topology
Cooling concept
Environmental Protection rating
Altitude
Relative Humidity

433/566/195
30KG
-25℃ ... +60℃
≤35dB(A)
＜0.5W
Transformerless
Natural
IP65
2000m without derating
0~100%

433/566/195

31.1KG
-25℃ ... +60℃
≤35dB(A)
＜0.5W
Transformerless
Smart cooling
IP65
2000m without derating
0~100%

433/566/195

31.1KG
-25℃ ... +60℃
≤35dB(A)
＜0.5W
Transformerless
Smart cooling
IP65
2000m without derating
0~100%

Certificates and ApprovalsCE, VDE0126-1-1, VDE-AR-N4105, IEC 62109-1/-2, C-tick, AS/NZS 3100, AS4777, EN61000-6-2 , EN61000-6-3, IEC61727, IEC62116, G83, EN50438
