Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Garbage Truck Gasoline & CNG Engine T-King 4X2
Model NO.:ZB5034
Type:Roll Off
Certification:ISO9000, CCC
Volume:3001-6000L
Emission Standard:Euro 4
Transmission Type:Manual
Engine Type:4 Stroke
Payload:3t
Fuel:Gasoline & CNG
Drive Wheel:4×2
Brand:T-King
Models:Small
Usage:Arm Type
Chassis:Zb1034bdc3f
Condition:New
Chassis Brand:T-King
Cabin:Single Row
Dual-Fuel Engine:88HP/78HP Euro4 Gasoline & CNG
Gear Box:5 Forward Gears & 1 Reverse
Front / Rear Axle:1.5t / 3t
Brake System:Oil Braking
Tire:185r14
Compartment Volume:3 Cubic to 5cubic
Equipment:Hydraulic System and Operating System
Export Markets:Global
Trademark:SUNY
Packing:RO-RO, Bulk Freighter
Standard:ISO&CCC
Origin:China
Production Capacity:500 Unit / Year
volume:3 cubic ~ 5 cubic
quanchai 4-cylinder Gasoline&CNG engine 88hp/78hp
Brake system:Oil braking
Single row
1.dump garbage truck
2.hanging dustbin garbage truck
3.roll arm garbage container truck
4.swing arm garbage container truck
5.compactor garbage truck
6.movable refuse compactor with truck
| Products Technical Specification | ||
| Brand-Series | T-KING | |
| Product Name | 4*2 Roll-off Garbage Truck | |
| Fuel type | Gasoline & CNG | |
| Emission Standard | Euro 4 | |
| Cabin | Single row | |
| Chassis standard configuration | ||
| Chassis model | ZB1034BDC3F | |
| Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 4455*1640*2085 |
| Wheel base | 2700 | |
| Front / Rear track base | 1180 / 2310 | |
| Front / Rear overhang | 1010 / 745 | |
| Weight data (kg) | G.V.W | 3490 |
| Curb weight (chassis) | 1670 | |
| Max payload | 3000 | |
| Whole vehicle main performance | Max. speed (km/h) | 80 |
| Max. slope of climb (%) | 30 | |
| Engine | Model | DK12-05 |
| Type | Gasoline & CNG | |
| Maximum power | 88hp / 78hp | |
| Number of cylinders | 4 | |
| Displacement (lit) | 1.240 | |
| Engine Manufacturer | Chongqing xiaokang power Co., Ltd. | |
| Gear box | Number of gears | 5 forward gears & 1 reverse |
| Axle | Front / Rear Load capacity(ton) | 1.5 / 3 |
| Suspension | Front / Rear Spring plate | 6 / 5+3 |
| Steering Wheel | left/right hand drive | LHD |
| Brake system | Service brake | Front disc / rear drum |
| Electric device | Voltage (V) | 12 |
| Tyres & Quantity | 185R14 6PR & 6+1 | |
| Special configuration | ||
| garbage box capacity | 3cbm-5cbm | |
| Box Material | Carbon steel Q235 Optional stainless steel | |
| Max. tilt angle | 48 | |
| Hooking time(s) | ≤60 | |
| Unload time(s) | ≤60 | |
| Max.hydraulic pressure (Mpa) | 18 | |
