Loading Port:China main port
Payment Terms:TT OR LC
Min Order Qty:5 m.t.
Supply Capability:100000 m.t./month
Thickness: 0.12-1.5mm
Width: 20-1250mm
Zn: 60-275g/m2
Grade: SGCC, DX51D, DC51D, ETC.
NAME | PPGI | GALVANIZED | GALVALUME/ALUZINC |
CERTIFICATE | ISO9001:2008 | ||
STANDARD
| EN10142 JIS G3302 GB/T-12754-2006 | ASTM A653 JIS G3302 SGCC/SGCH GB/T2518 European Standard | ASTM A792 JIS G3321 JIS G3317
|
GRADE
| CGCC CGCH CGCD1-CGCD3 CGC340-CGC570 GRADE
| SS GRADE33-80 SGCC SGCH SGCD1-SGCD3 SGC340-SGC570 SGCC DX51D | GRADE33-80 SGLCC SGLCD SGLCDD SGLC400-SGLC570 SZACC SZACH SZAC340R |
Mode No of prepainted steel coil | 0.14MM-1.5MM*1250MM OR UNDER | (0.14-1.5)*1250MM OR UNDER | 0.14MM-1.5MM*1250MM OR UNDER |
Type of prepainted steel coil
| Steel coil Steel sheets/plates Corrugated steel sheets/plates
| Steel coil Steel sheets/plates Corrugated steel sheets/plates | Steel coil Steel sheets/plates Corrugated steel sheets/plates
|
Technique of prepainted steel coil | Hot rolled-cold rolled -galvalume /galvanized -PPGI/PPGL | Hot rolled-cold rolled - galvanized | Hot rolled-cold rolled -galvalume /Aluzinc
|
Surface treatment of prepainted steel coil | Mini/regular/big/zero spangle, Chromate treatment /chromate-free treatment /untreated unoile/oiled, TENSION LEVELLERT SKIN PASS anti-fingerprint/un-anti-fingerprint, Coating,color | Mini/regular/big/zero spangle, Chromate treatment /chromate-free treatment /untreated unoile/oiled, TENSION LEVELLERT SKIN PASS anti-fingerprint/un-anti-fingerprint, Coating
| |
Application of prepainted steel coil | Structural use ,roofing, commercial use, household appliance, industry, family | ||
SPECIAL APPLICATION | Wear resistant steel, high- strength - steel plate | ||
Color coated steel sheets are a new-type pre-coated steel product developed rapidly in the past thirty years. Color coated steel sheets are made on high-speed continuous coating lines through a number of processes such as chemical pretreatment, primary coating and finish coating, thus they have better coating quality than single piece coating.
Color coated steel sheets feature excellent decorativeness, bendability, corrosion resistance, coating adhesion and color fastness. They are ideal substitutes for wood panels in the construction industry because of their good economic features such as convenient installation, conservation of energy and resistance to contamination.
The rapid development of color coated steel sheets is mainly attributed to their good economic, social and environmental properties. They are being used in more and more areas.
Structural Diagram of Color Coated Steel Sheet
| Technical specification: |
| The size range of our color coated steel sheet |
| Thickness(mm): 0.14-1.2 |
| width(mm): 700-1250 |
| Max steel roll weight(kg):6000 |
| Inside diameter of steel roll(mm):508 |
Scope of Application: Exterior decoration of buildings: Roof and wallboards of industrial, commercial, residential and public facilities Home appliances: Oil/gas boilers, rice buckets, portable gas burners, etc.
|
Packing
Each bare coil to be securely tied with two bands through the eye of coil (or not) and one circumferential, the contact points of these bands on the coil edge to be protect with edge protectors. Coil then to be properly wrapped with water proof /resistant paper, it then to be properly and completely metal wrapped. And each packed coil to be properly wrapped with band, three-six such band through the eye of coil at about equal distance, and two-four such bands securely tied around belly of coil at about equal distance.
