Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Vehicle Truck 40, 000L Heavy Duty 8X4
Model NO.:40, 000L Fuel Tank
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Tank Volume:>30000L
Drive Wheel:6×4
Seats:≤5
Horsepower:351-450hp
Engine Capacity:>8L
Storage:Oil
Tire Type:Tubeless
Tire Certification:CCC
Tire Design:Tubeless
Condition:New
Brand:Sinotruk-HOWO
Driving Type:6*4
Cab:Hw79, 2 Seats with 2 Beds
Engine:371HP, Euro2
Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:SINOTRUK
Packing:Nude
Standard:CCC
Origin:China
HS Code:8704190000
Production Capacity:30000 Units Per Year
Driving type: 6*4
Cab: HW79, 2 seats with 2 beds, left hand drive, with A/C
Engine: 371hp, Euro2
Transmission: HW19710, 10 forward and 2 reverse
Front axle: HF9, with loading capacity: 2*9000kgs
Driving axle: HC16, with loading capacity: 2*16000kgs
Tire: 12R22.5, including one spare tire
Fuel tanker Trailer: 40, 000L, different compartement can be seperated.
Weight | Curb Weight(kg) | 8800 | |
Gross Vehicle Weight(kg) | 25000 | ||
Gross Combination Weight(kg) | 50000 | ||
Dimension | Overall Dimensions(mm) | Length | 6800 |
Width | 2496 | ||
Height | 2958(3718) | ||
Wheel Base(mm) | 3225+1350,3200+1400 | ||
Minimum Ground Clearance(mm) | 298 | ||
Performance Parameters() | Maximum Speed(km/h) | 102 | |
Economic Speed(km/h) | 82 | ||
Maximum Gradability(%) | 35 | ||
Minimum Turning Diameter(m) | 15 | ||
Specification | Cabin | HW76(2 seats and 1 bed) | |
Engine | Model | WD615.87 | |
Net Power(Hp)/Rotating Speed(r/min) | 290/2200 | ||
Maximum Torque(Nm)/Rotating Speed(r/min) | 1160/1100-1600 | ||
Gearbox | HW15710 | ||
Clutch(mm) | 430 | ||
Rear Axle | Type | ST16 | |
Gear Ratio | 4.42 | ||
Oil Tank(L) | 400 | ||
Tires | 12.00R20, 12.00R22.5, 295/80R22.5, 315/80R22.5 |
