Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Trucks Heavy Capacity 350HP 8X4
Model NO.:QXFTA002
Transmission Type:Automatic
Power:Diesel
Load Capacity:1-10t
Emission Standard:Euro 3
Tank Volume:5001-10000L
Drive Wheel:4×2
Seats:≤5
Horsepower:150-250hp
Engine Capacity:4-6L
Storage:Oil
Tire Type:Solid Tire
Tire Certification:ECE, ISO, DOT
Tire Design:Radial
Condition:New
Export Markets:North America, Southeast Asia, Africa, Mid East, Eastern Asia
| Technical Specification | |||||||
| Overall dimensions(L×W×H) | 11990×2500×3750(mm) | ||||||
| Emission standard | Euro3 | ||||||
| Cab | Single row, 3 passengers allowed in cab | ||||||
| G.V.W. | 31000(kg) | ||||||
| Curb weight | 3300(kg) | ||||||
| Loading capacity | 3065(kg) | ||||||
| Fuel type | Diesel | ||||||
| Engine & Chassis Specification | |||||||
| Chassis | CQ1315HTGG466V | ||||||
| Engine | SC10E350Q4 | ||||||
| Max.speed | 95(km/h) | ||||||
| Power | 350(hp) | ||||||
| Displacement | 10420(ml) | ||||||
| Axle base | 1800+4265+1350(mm) | ||||||
| F/R wheel-base | 2006,2006/1850,1850(mm) | ||||||
| F/R overhang | 1435/2780(mm) | ||||||
| Axle load | 6500/6500/18000(kg) | ||||||
| Tyre | Standard equipped 11.00-20 18PRranhou tyre | ||||||
| Tank Specification | |||||||
| Tank dimensions | 9000×2500×1800(mm) | ||||||
| Tank volume | 25-30(cbm) | ||||||
| Tank material | aluminium alloy 5083,5182,5454 | ||||||
| Tank thickness | 5(mm), optional 6(mm) | ||||||
