Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Truck Olong 6X4 20000L Fuel Tank Truck
Model NO.:SX5255GYYDM564
Transmission Type:Automatic
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 3
Tank Volume:15001-30000L
Drive Wheel:6×4
Seats:≤5
Horsepower:251-350hp
Engine Capacity:4-6L
Storage:Oil
Tire Type:Inner Tube
Tire Certification:GCC
Tire Design:Tubeless
Condition:New
Brand:Shacman
Series:Olong
Colour:Red, Yellow, White and So on
Fuel Tank:20000L
Tyre:12.00r20
Export Markets:Global
Trademark:Shacman Olong
Packing:Nude Packing or Can Be Discounting
Standard:CE, RoHS
Origin:Shanxi, China
HS Code:87163110
Production Capacity:10000PCS/Year
Engine model: WD12.336 EURII
Capacity of tank: 18m3
Shacman O'long 6X4 18m3 336HP fuel tank truck
I. CHASSIS
MANUFACTURER: SHAANXI HEAVY DUTY AUOMOBILE Co., Ltd
ORIGIN COUNTRY: THE PEOPLE'S REPUBLIC OF China
Brand: O'long
Traction type: 6X4
Driving type: LHD (RHD is option)
| Product | SHACMAN 6*4 oil tanker truck | |||
| Chassis model | ||||
| Chassis parameters | Overall dimensions | mm | 9719x2500x3400 | |
| Gross weight | kg | 25000 | ||
| Kerb weight | 11500 | |||
| Rated payload | 13500 | |||
| Suspension F/R | mm | 1525/2519 | ||
| Wheel base | 4325+1350 | |||
| Drive type | 6*4 | |||
| Number of axles | 3 | |||
| Axle-load | Kg | 7000/18000/18000 | ||
| Number of Spring leafs | 9/12 | |||
| Tire specification | 12.00-20 | |||
| Number of Tires | 10 | |||
| Allowable passengers in cab | 3 | |||
| Engine | Engine model | WD615.50 | ||
| Type of fuel | Diesel | |||
| Displacement/power | ml/hp | 9.726/280 | ||
| Max speed | Km/h | 92 | ||
| Emission standard(TAS) | EURO II | |||
| Tank | 1.Effective cubage: 19000L 2.Tank dimensions: 9000×2110×1600mm 3.Material: high quality carbon steel, stainless steel, glass steel or plastic steel | |||
