Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Truck Foton 4X2Aluminum Oil Tank Truck 3cbm
Model NO.:BJ1046V8JD4-A
Transmission Type:Manual
Power:Diesel
Load Capacity:1-10t
Emission Standard:Euro 2
Tank Volume:＜5000L
Drive Wheel:4×2
Seats:≤5
Horsepower:＜150hp
Engine Capacity:＜4L
Storage:Oil
Tire Type:Solid Tire
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Tubeless
Condition:New
Engine:80HP/95HP/102HP/120HP/140HP
Tire:6.5-16
Volume of Tank:3000L, 4000L, 5000L,
Air Conditioner:A/C or Without A/C
Driving Type:LHD or Rhd
No. of Compartment:No. of 1/2/3/4/5/6 Compartments
Driving Axle:4X2/6X4/8X4
Other Key Parts:Discharged Pump/ Discharged Valve/API Manhole
Pto:with 50# or 60# Pto
Brand Name:Foton Forland4X2 Mini Aluminum Fuel/Oil Tank Truck
Export Markets:Global
Trademark:CLW
Packing:Waxed Before on Board
Standard:CCC, ISO14001
Origin:Hubei
HS Code:8705909990
Production Capacity:1500 Unit/Month
Fuel tanker series
1 Applied carbon steel sheet Q235-A; Stainless steel; Aluminium alloy that in accordance with the international standard. Thickness is 5-10mm.
2 Apply the famous pump.
3 The main parts implements automatic welding, while the accessories apply carbon dioxide welding to ensure the tank in good performance.
4 Sub crossbeam apply rectangle steel sheet that thickness more than 5mm, stick out in one time.
5 Fire extinguisher replaced on the back of the truck for the emergency.
6 Painting held more tolerance and coherence, can make sure the tank in good situation more than 5 years.
| Item | unit | parameter | |
| Vehicle model | CLW5060GJY Fuel Tanker | ||
| Overall dimensions | mm | 5990×1940×2300 | |
| Fact cubage | M³ | 5 | |
| GVW | kg | Appro×6225 | |
| Mass in working order | Appro×4115 | ||
| Tank dimensions | mm | 4050x1700x1100 | |
| Wheel base | 3300 | ||
| F/R track base | 1032/1658 | ||
| Approach/departure angle | ° | 17/15 | |
| Exhaust/hp | ml/kW | 3298/ 95 | |
| Max speed | km/h | 95 | |
| Tire specification | 6pieces, 6.50-16 | Engine type | SD4BW70-3R |
| Traction system | 4×2 | Numbers of leaf spring | 8/9+5 |
| Number of axles | 2 | Electric system | 24v |
| Operation control system | Electrically hydraulic control | Allowable passengers in cab | 3 |
| Equipment | Material: 5mm Aluminum can choose flow meter, tanker piston and bobbin disk Tank can be separated to several unattached small tanks to fill different fuels | ||
| Engine | GuangXi Yunei SD4BW70-3R diesel engine,95hp | ||
| Warranty | 12 month, from the date of supply | ||
