Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Model NO.:HZZ5256GJY
Transmission Type:Manual
Power:Diesel
Emission Standard:Euro 3
Condition:New
Tank Material:Stainless Steel
Full Capacity:24500L
Total Mass:31000kg
Rated Payload:Approx. 16500kg
Chassis:Faw Group
Port of Delivery:Shanghai/Ningbo
Export Markets:Global
Trademark:China Jinggong
Packing:Nacked
Standard:ISO9001
Origin:Zhejiang China
HS Code:8704230090
Production Capacity:10units/Months
Vehicle Main DimensionsOverall dimensions (L x W x H)mm8000× 2490× 3200
Wheel base (mm)4500/4700
Wheel track (front/rear) (mm)1900/1800
Weight in KGSTare Weight6200
Payload8000
Front axles loading capacity1x5000
Rear axles loading capacity1x9000
Max. Driving speed(km/h)90
Engine BrandCummins
ModelEQB160
Type4-stroke direct injection, 6-cylinder in-line, turbo-charging and inter-cooling
Horse Power(HP)160 HP
Emission standardEuro II
Gearbox6 Forwards gear & 1 reverse gear
Steering power steering
Tire 9.00-20, 9.00R20 meridian tyres optional
Tank capacity10, 000 liters, 4 mm tank and wave-proof board, 5mm end plate
Pump With one pump, the fuel can be pumped in, also pumped out.
Production cycle20-25 days
| Model | HZZ5256GJY |
| Chassis Model | HFC1255KR1T |
| Chassis Manufacturer | JAC |
| Outer dimension(mm) | 11280×2495×3350 |
| Tank Effective Volume (m3) | 20 |
| Transporting Medium | Gas/Diesel |
| Wheelbase (mm) | 1700+5000 1700+4600 |
| Total mass(Kg) | 24900 |
| Tare weight(Kg) | 11205 |
| Payload(Kg) | 13500 |
| Engine model/Engine power(kw) | CA6DF3-18E3/143 CA6DF3-20E3/155 |
| Fuel type | Diesel |
| Vehicle emission standard | (National III) |
| Spec. of Tyre | 10.00-20 10.00R20 11.00-20 11.00R20 |
| Max. Speed(km/h) | 98 |
