Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Truck 9000L , Oil Tank Truck
Model NO.:VL5102
Transmission Type:Manual
Power:Diesel
Load Capacity:1-10t
Emission Standard:Euro 3
Tank Volume:5001-10000L
Drive Wheel:4×2
Seats:≤5
Horsepower:150-250hp
Engine Capacity:6-8L
Storage:Oil
Tire Type:Solid Tire
Tire Certification:ISO
Tire Design:Radial
Condition:New
Tank Truck:Fuel Tank Truck
Chassis Brand:Dongfeng
Drive Side:Left/Right
Engine Model:Cummines
Color:Optional
Export Markets:Global
Trademark:Veldlion
Packing:Nude Packing or Roro Ship
Standard:3C, ISO
Origin:Hubei
HS Code:8716311000
Production Capacity:3000 PCS Per Year
1. Factory direct supply, competitive price with advanced quality;
2. Can offer various tanker truck, like as oil tanker, bulk cement tanker truck, water tanker truck, mixer tanker truck, LPG...
3. Tanker volume: 5CBM-50CBM
4. Chassis is optional, DFAC, FOTON, SINO, SHACAN, FAW, CAMC, ISUZU...2
| 9000L FUEL TANK TRUCK/OIL TANK TRUCK | ||
| Product Model | HLQ5090GJYE DFAC 4*2 fuel tanker truck | |
| Overall dimensions (L*W*H) | 7000*2300*2850 mm | |
| G.V.W | Approx 9400 kg | |
| Net weight | Approx 4225 kg | |
| load | Approx 8000 kg | |
| Approach/Departure angle | 21/12 ° | |
| F/R suspension | 1180/2020 mm | |
| Axle load | 3250/6150 kg | |
| Max speed | 95 km/h | |
| Allowable passengers | 2+1 | |
| Cab type | Flat top. one row and a half. Turning cab. | |
| Cab inner | Optional A/D | |
| CHASSIS | ||
| Chassis model | EQ1090T9ADJ3AC | |
| No. of axle | 2 | |
| Wheel base | 3800 mm | |
| No. of tire & specification | 7.50-16(optional 7.50R16) | |
| No. of leaf spring pieces | 8/10+7 | |
| F/R tread | 1831/1640 mm | |
| Tractions | 4*2 | |
| Braking system | Air braking | |
| Operation control system | Power steering | |
| Electric system | 24 V | |
| Transmission | 5 forward gears, 1 reverse gear. Manual | |
| ENGINE | ||
| Engine model (emission) | B140 33 (EURO 3) optional: ISDe 140 30 / CY4102-E3C | |
| Manufacturer | Cummins Engine | |
| Fuel type | Diesel | |
| House power | 140 hp / 103 kw | |
| Exhaust | 3900 ml | |
| FUEL TANK TRUCK EQUIPMENT AND FUNCTION | ||
| Tank capacity | 7000L ~ 10000L ( 7 m3 ~ 10 m³) | |
| Tank dimensions | By customer's needs | |
| Tank material | Q235A (optional: Q345 / Stainless steel) | |
| Tank shape | Optional | |
| Pump | Equipped with the specific pump to suck and discharge the oil automatically. | |
| Optional equipments | Computer control injector / Fuel hose / Fuel gun / Flow meter. Tank can be separated to several unattached small tanks to fill different oil. | |
