Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Truck 8X4 40 Cbm Stainless Steel Full Traile
Model NO.:CA5310GYYT4
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Tank Volume:＞30000L
Drive Wheel:8×4
Seats:≤5
Horsepower:251-350hp
Engine Capacity:＞8L
Storage:Oil
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Condition:New
Truck Type:Tanker Truck
Type:Fuel Tank Truck
Driving:8X4
Brand:Faw
Volume:40cbm
Colour:Red, White, Blue
Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia
Trademark:FAW
Packing:Nude Packing
Standard:ISO
Origin:China
HS Code:8703109000
Production Capacity:50PCS/Month
Product: FAW rear double axles Fuel tank truck, refuel truck.
Chassis: CA1310P7K2L7T4EA80
Gross weight: 55000 (kg)
Rated payload: 35000 (kg)
Kerb weight: 18005 (kg)
Overall dimension: 11800X2480X3800 (mm)
Tank dimension: 9500X2300X1500 (mm)
Approach/ Departure angle: 14/10 (degree)
Front/ Rear suspension: 1375/2550 (mm)
Max speed: 85 (km/h)
Engine: CA6DE3-28E3 WP10.336
Displacement: 6618 9726 (ml)
Power: 280HP/ 336HP
Manufacturer: FAW/WEICHAI.
Emission standard: GB3847-2005, GB17691-2005 Euro 3
Axle Nos: 3
Wheelbase: 1800+5725+1350 (mm)
Front tread: 1914 (mm)
Rear tread: 1847 (mm)
Tyre no.: 12.
Tyre specification: 12.00R20, 12.00-20, 11.00R20, 11.00-20
Fuel type: Diesel
Leaf spring nos: 4/10
Axle load: 7500/26000
| Vehicle model | CA5403GHY Oil tank truck | Batch No. | 197 |
| Manufacturer | FAW | Brand name | FAW |
| Overall dimension(mm) | 11980×2480×3800 | Total weight (Kg) | 55000 |
| Body internal dimension(mm) | ×× | Curb weight(Kg) | 18000 |
| Approach/departure angle | -/12 | Max speed(km/h) | |
| Front/rear hang(mm) | -/2130 | Vehicle identification code | LFA |
| Chassis model | |||
| Engine model | Engine manufacturer | Emission | Power |
| FAW/ WEICHAI | Euro2 | 280hp,336hp | |
| Fuel type | Diesel | Tyre number | 12 |
| Axle number | 4 | Tyre specification | 11.00-20,11.00R20, 12.00-20,12.00R20 |
| Wheelbase | 1800+5730+1310 | Front wheel distance | - |
| Axle load | 9000-/26000 ( parallel ) | Rear wheel distance | 1840/1840/1840 |
| Leaf spring number | -/8/8/8 | ||
