Fuel Tank Truck 8X4 30000 Litre Heavy

Loading Port:Shanghai

Payment Terms:TT OR LC

Min Order Qty:1 PCS

Supply Capability:1500 PCS/month

Product Description:

Fuel Tank Truck  8X4 30000 Litre Heavy

Product Details

Basic Info.

Model NO.:ZZ5317



Transmission Type:Manual

Power:Diesel



Load Capacity:31-40t

Emission Standard:Euro 3



Tank Volume:>30000L

Drive Wheel:8×4



Seats:≤5

Horsepower:251-350hp



Engine Capacity:>8L

Storage:Oil



Tire Type:Solid Tire

Tire Certification:ISO



Tire Design:Radial

Condition:New



Tank Truck:Truck

Export Markets:Global

Additional Info.

Trademark:Veldlion



Packing:Nude Packing or Roro Ship

Standard:3C, ISO



Origin:Hubei

Production Capacity:3000PCS Per Month

Product Description


1.Factory direct supply, competitive price with advanced quality;
2. Can offer various tanker truck, like as oil tanker ,bulk cement tanker truck, water tanker truck,mixer tanker truck, LPG...,
3. Tanker volume: 5CBM-50CBM
4. Chassis is optional, DFAC, FOTON, SINO, SHACAN,FAW,CAMC,ISUZU....


Truck Model

ZZ1317N4667C1

Truck Brand

SINOTRUK_HOWO

Driving Type

Left hand driving

Dimension(Lx W xH) ( unloaded )( mm )

11980x2496x3700

Carriage inner dimension(LxWxH) ( mm )

9160*2495*1730

Approaching angle/Departure angle ( ° )

 1 6 /1 6

F/R track base(mm)

2022/1830

Tank capacity( m 3  )

3 5

Medium

Gasoline

Gear oil pump

Model

76YCB-40 ( F )

flux     m 3 /h

40

In /out cabiber   mm

76

RPM   r/min

960

Remarks :

oil pump mod el  with F, represent relief valve, used for oil tanker truck with oil gun.

Wheel base (mm)

1800+4600+1350

Max speed ( km/h )

9 5

Curb weight ( kg )

11280

Loading Weight ( kg )

35000

Engine

(Steyr technology,

made in China)

Model

WD615 , water-cooled , four strokes , 6 cylinders in line with

water cooling , turbocharged and inter-cooling, directly injection

Fuel type

Diesel

Horse Power, max ( kw/rpm )

340 HP.  380 HP

Emission

EURO II I

Fuel tanker capacity  ( L )

300

Transmission

Model

HW1 9 710CL,10 forwards and 2 reverse

Brake system



Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

ZF8098

Front axle

HF7

Rear axle

MCY13Q

Color

Optional

Tire

11.00-20 /  12.00-20/   295/80R22.5

Tire quantity

12+1 spare

Electrical system



Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

HOWO76 cab with one sleeper and air conditioner,

 all-steel forward control.
