Fuel Tank Truck 4X2 10000L Light Diesel Oil Delivery

Loading Port:Shanghai

Payment Terms:TT OR LC

Min Order Qty:1 PCS

Supply Capability:1500 PCS/month

Product Description:

  Fuel Tank Truck 4X2 10000L Light Diesel Oil Delivery

Product Details

Basic Info.

Model NO.:CSC5112GJY3



Transmission Type:Manual

Power:Diesel



Load Capacity:11-20t

Emission Standard:Euro 3



Tank Volume:10001-15000L

Drive Wheel:4×2



Seats:≤5

Horsepower:150-250hp



Engine Capacity:6-8L

Storage:Oil



Tire Type:Inner Tube

Tire Design:Radial



Condition:New

Truck Type:Tanker Truck



Type:Light Truck

Export Markets:Global

Additional Info.

Trademark:Dongfeng



Packing:Nude Packing

Origin:China



Production Capacity:30000piece/Year

Product Description


ModelCSC5112GJY3
ChassisEQ1110T9ADJ3AC
Specification:
(kg)Ranted payload8500
Overall dimension:(mm)6995×2300×2750
Kerb mass: 4500kg
Tank dimension (mm)4900×2020×1360
Total mass 11495Wheel base (mm)3800
Engine:
ModelCY4102-E3C
Emission standard Euro III
Rated power/displacement88/4500
Manufacture Dongfeng Chaoyang Diesel Engine Co.,Ltd.
SpecificationMax.Speed (km/h)90
Track width (mm)
Front axle1831,1750
CabinFlat roof Rear axle1640,1586
Leaf spring 11/9+7,8/10+7
Overhang (mm):
Front overhang 1180
Tire number 6
Rear overhang 2320
Tire size7.50-16
Angel (°)Approach22
Departure 12
Number of axle 2

Tank equipment:
Tank capacity: 10,000Liters
Computer tax oil pump
15meters long return reel and refueling gun
Pump with rapid in-and -out progress of oil function
2 long tube for the tank
2 fire extinguishers
1 Ladder
Both sides and rear bumper

Dongfeng DFL5253 capacity fuel tank truck parameters
Load weight(kg)12500Curb weight of chassis(kg)12305
Total mass(kg)25000Overall dimension(mm)11880*2480*3100,3690
Approach/Departure angle20/20Max. speed(km/h)90
Van capacity(m 3 )18-26Wheel tread(mm)1980/1980/1860
Front/rear overhang(mm)1460/3040Wheelbase(mm)1950+5350
Engine modelEngine manufacturerDisplacement(ml)Power(kw)
B190 33Dongfeng Cummins Engine Co.,Ltd6700190
Axle number3Emission standardEuro 2
Fuel typeDieselTire number8
Leaf spring8/8/9+9,3/3/4+3,8/8/8+8Tire model10.00-20,10.00R20,
11.00-20,11.00R20
Cab capacity3 peopleAir-conditionOptional
