Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Truck 4*2 10000L（CQ1254HTG434)
Product Details
Model NO.:VL5120
Transmission Type:Automatic
Power:Gas/Petrol
Load Capacity:1-10t
Emission Standard:Euro 3
Tank Volume:5001-10000L
Drive Wheel:4×2
Seats:≤5
Horsepower:251-350hp
Engine Capacity:6-8L
Storage:Oil
Tire Type:Inner Tube
Tire Certification:GCC
Tire Design:Tubeless
Condition:New
Fuel:Diesel
Certification:ISO9000 & CCC
Engine Type:4 Stroke
Volume:>10000L
Type:10000L Fuel Tank Truck
Payload:16t
Export Markets:Global
Trademark:VELDLION
Packing:Nude Packing or Roro Ship
Standard:CCC $ ISO9001
Origin:Hubei, China
HS Code:8716311000
Production Capacity:3000 PCS Per Month
Quick Details:
1. Name: Oil tank truck
2. Tank material: Aluminum Alloy 5083
3. Drive Wheel: 4*2
4. Horsepower: 235(320HP)
5. Chassis: Dongfeng Nissan Diesel
7. Full Capacity: 10000L
| 10000L Oil Truck | |
| Chassis model | EQ5160GKJ |
| cabin | Flat head Single row with sleeper cabin,EURO3 4x2 drive |
| Outline size(mm) | 8350*2480*3120 |
| Tank capacity(L) | 10000-12000 |
| Max mass(kg) | 15600 |
| Curb weight(kg) | 6605 |
| Engine model | B190 33 |
| Displacement/power(ml/kw) | 5900/140 |
| Wheelbase(mm) | 4500,4700,4950 |
| tire | 10.00-20,10.00R20 |
| Steel spring | 9/10+8 |
| transmission | 5-speed with one over drive |
| Max speed(km/h) | 85 |
| Approach/departure angle | 25/22 |
| F/R track base | 1250/2400 |
| Remark 1 | Vehicle protection materials : carbon steel with Q235 |
| Remark 2 | Can meet special requirements like adding AC, change color, order RHD drive, extra side warming lights, order extra main accessories for engine, etc. |
| payment | 30% TT for down payment,70% TT balance before delivering to CN port |
| Production cycle | About 15 working days after order |
| packing | Waxing |
| Tank thickness | 5mm-6mm carbon steel |
| Emission standard | GB3847-2005,GB17691-2005 EURO3 |
