Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Tank Truck 3000L ~ 5000L 120HP 4X2
Model NO.:HFC1071
Transmission Type:Manual
Power:Diesel
Load Capacity:1-10t
Emission Standard:Euro 4
Tank Volume:＜5000L
Drive Wheel:4×2
Seats:≤5
Horsepower:＜150hp
Engine Capacity:＜4L
Storage:Oil
Tire Type:Inner Tube
Tire Certification:ISO, CCC
Tire Design:Bias
Condition:New
Chassis Brand:JAC
Cabin:Single Row, with A/C
Engine:88kw / 120HP
Gearbox:5 Forward Gears & 1 Reverse
Drive Axle:4.5t
Tire:7.00r16
Tanker Load:3000L 4000L 5000L
Tanker Material:Carbon Steel Optional Stainless Steel, Aluminum
Tanker Thickness:4 Mm
Equipment:Fuel Pump Optional Flow Meter, Tanker, Refueling G
Export Markets:Global
Trademark:SUNY
Packing:After Waxing by Container, RO-RO, Bulk Freighter
Standard:ISO&CCC
Origin:Hubei Suizhou
Production Capacity:500 Unit / Month
4x2 Oil tanker truck
88kw / 120hp tanker truck
| Products Technical Specification | ||
| Brand-drive | JAC-4*2 | |
| Chassis Model | HFC1071 | |
| Cabin | Single row | |
| Fact Cubage (L) | 4000 | |
| Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 5995*1950*2160 |
| Tank dimensions | 3700*1600*1024 | |
| Wheel base | 3308 | |
| Front overhang | 1105 | |
| Rear overhang | 1530 | |
| Min. ground clearance | 450 | |
| Weight data (kg) | G.V.W | Approx 6995 |
| Curb weight (chassis) | Approx 3720 | |
| Max payload | 3000 ~ 5000 | |
| Whole vehicle main performance | Max. speed (km/h) | 80 |
| Engine | Model | HFC4DA1-2C |
| Maximum power | 88kw / 120hp | |
| Number of cylinders | 4 | |
| Displacement (L) | 2.771 | |
| Engine Manufacturer | Anhui Jianghuai Automobile Co., Ltd. | |
| Gearbox | Number of gears | 5 forward gears & 1 reverse |
| Axle | Rear Load capacity | 4.5T |
| Suspension | Front/Rear Leaf spring | 7/4+5,8/4+5 |
| Steering Wheel | left/right hand drive | LHD |
| Brake system | Service brake | Oil braking |
| Parking brake | Power Steering | |
| Electric device | Rated voltage | 24V |
| Tire & Quantity | 7.00R16 & 6+1 | |
| Up-parts Description | ||
| Tank dimensions(mm) | 3700*1600*1024 | |
| Standard configuration | Shape | Oval or Square |
| Material | Carbon steel Q235 | |
| Thickness | 4 mm | |
| 1-chamber,fuel pump,two artesian mouth, two pipelines,toolbox | ||
| Optional Configuration (√ : Standard Equipment o: Optional ×: Not ) | ||
| A/C | o | |
| Cabin,Half row | × | |
| Power Steering | √ | |
| Radial tire | √ | |
| ABS | o | |
| Color | o | |
| Refueling equipment | Fiscal tanker, refueling guns , refueling reel, flow meter. European standard manhole,etc. | |
