Fuel Tank Truck 25cbm Chinese Hot Selling

Loading Port:Shanghai

Payment Terms:TT OR LC

Min Order Qty:1 PCS

Supply Capability:1500 PCS/month

Product Description:

Fuel Tank Truck 25cbm Chinese   Hot Selling

Product Details

Basic Info.

Model NO.:CA5250GYYP63K1L5T3E4



Transmission Type:Manual

Power:Diesel



Load Capacity:21-30t

Emission Standard:Euro 4



Tank Volume:15001-30000L

Drive Wheel:6×2



Seats:≤5

Horsepower:251-350hp



Engine Capacity:6-8L

Storage:Oil



Tire Type:Solid Tire

Tire Certification:ECE, GCC, ISO, DOT



Tire Design:Radial

Condition:New



Tank Capacity:25000L

Steering Type:Left- Hand Drive( Right-Hand Drive Can Opt)



Transmission:8 Gear

Tire Specification:11.00r20



Tyre Number:8

.Engine Type:Bf6m1013-24e4



Export Markets:Global

Additional Info.

Trademark:FAW



Packing:Bulk and Wax Covered

Standard:CE



Origin:China

HS Code:8705909090



Production Capacity:2000units Per Year

Product Description


I. Vehicle Parameter

1.model.name

refueling truck

2.brand name

FAW

3.Overall dimension(mm)

11000,10500×2500×3454,3250

4.curb weight(kgs)

10325

5. tank  volume

25CBM

6.Tank material

carbon steel Q235

7. cab seats(man)

3,2

8.Max speed((Km/h))

79

9.Transmission

8 gear

10.brake system

Air brake/oil brake

11..Approach/

departure angle(°)

17/14

12.front/rear hang(mm)

1400/2500

14.steering type

Left- hand drive( right-hand drive can opt)

15.cabin

 White (other colors are available), Flat, luxurious interior trim and seat,

with air conditioning and power steering,forward flip.

16.Performance characteristic

A, with multiple baffle plates in the tank, the tank has the

advantages of high intensity, stability, transporting safety etc.

B, Oil pump is installed to suck or discharge oil, with high suction pressure and speed.

C, Computer refueling machine is installed, with a 15 meterautomatic return oil pipe

and refueling gun, achieving mobile refueling fuction.

D, according to users' needs, the tank can be designedas a single compartment or

 several compartments to contain different oils.

E, according to users' needs, the side or the rear of the tank can be installed

1 to 3 self-flowing valves

II. Chassis parameter

1, Chassis model

CA5250GYYP63K1L5T3E4

Brand name

FAW

3.manufacturer

CHINA FAW GROUP

4.Drive type

6 x 2

5.Wheel base

1950+5150,1950+4650

6.Front track base

1950/1950

7.Rear track base

1847

8.Tire specification

11.00R20

9.tyre number

8

10.axle load

6510/6510/11500

11.axle number

3

III. Engine parameter

1.engine type(emission/power)

BF6M1013-24E4(7146 ml / 180kw )

2. Engine manufacturer

CHINA FAW GROUP

3.Fuel type

Diesel

4.Emissions standards

Euro 4
