Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Fuel Oil Tank Truck 8X4 Excellent Quality with Technology
Model NO.:NG80
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Tank Volume:15001-30000L
Drive Wheel:6×4
Seats:6-9
Horsepower:351-450hp
Engine Capacity:＞8L
Storage:Oil
Tire Type:Solid Tire
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Radial
Condition:New
Body:with Opening& Downloading and Top Loading Valves &
Export Markets:Global
Trademark:BEIBEN/NORTH BENZ
Packing:Nude Packing
Standard:ISO9001
Origin:China Mainland
HS Code:870423009
Production Capacity:10, 000units/Year
| Product | BEIBEN 8*4 oil tanker truck | |||
| Chassis model | ND5313GJYZ | |||
| Chassis parameters | Overall dimensions | mm | 11865×2500×3395 | |
| Gross weight | kg | 31000 | ||
| Kerb weight | 13720 | |||
| Rated payload | 17150 | |||
| Suspension F/R | mm | 1420/2745 | ||
| Wheel base | 1500+4750+1450 | |||
| Drive type | 8*4 | |||
| Number of axles | 4 | |||
| Axle-load | Kg | 6500/6500/18000 | ||
| Number of Spring leafs | 12/12/13 | |||
| Tire specification | 12.00-20 | |||
| Number of Tires | 12 | |||
| Allowable passengers in cab | 3 | |||
| Engine | Engine model | WP10.310E32 | ||
| Type of fuel | Diesel | |||
| Displacement/power | ml/hp | 9726/310 | ||
| Max speed | Km/h | 85 | ||
| Emission standard(TAS) | EURO II, III | |||
| Tank | 1.Effective cubage: 30000L 2.Tank dimensions: 9250×2460×1550mm 3.Material: high quality carbon steel, stainless steel, glass steel or plastic steel | |||
