Loading Port:Qingdao
Payment Terms:TT OR LC
Min Order Qty:20 m.t
Supply Capability:3000 m.t/month
1.Quick Details
Model Number: FAS-DB
Surface: Galvanized
Material: High Strength Steel
Type: Diagonal Brace
Certification: CE
Packaging & Delivery
Packaging Details:pallet
2.Product Description
Model No: FAS-DB
Product Name: Scaffolding System--Cross Brace With Single Coupler
3.Feature:
1. Made of Φ48.3mm x 3.20mm thickness steel tube,
Specification(mm): 2000(H)x2070/2570/3070(W) etc.
2. Surface: painted/cold (hot) dipped galvanized or to be order
3. Also can manufacture it as your requiremen
4.
Ring Lock System Scaffold Steel Plank (9.5" wide) | |||
Model | Description | Weight(kg) | Weight(lbs) |
AR.SSP.3050 | Ring Lock Steel Plank 3050mm (10') | 20.56 | 42.92 |
AR.SSP.2440 | Ring Lock Steel Plank 2440mm (8') | 17.01 | 35.13 |
AR.SSP.2130 | Ring Lock Steel Plank 2130mm (7') | 15.21 | 31.17 |
AR.SSP.1830 | Ring Lock Steel Plank 1830mm (6') | 13.47 | 27.34 |
AR.SSP.1520 | Ring Lock Steel Plank 1520mm (5') | 11.66 | 23.39 |
AR.SSP.1220 | Ring Lock Steel Plank 1220mm (4') | 9.92 | 19.56 |
AR.SSP.1150 | Ring Lock Steel Plank 1150mm (3'10") | ||
5.What is considerations of Scaffolding installation?
There must be a fire protection measures and specialist care, safety personnel patrol inspection when electricity, gas welding work on the scaffold,
(1) scaffold frontage hurtful to prevent falling objects protection is required.
(2) During take down the scaffolding, fencing and warning signs should be set up on the ground, prohibit others person besides the operator
