Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1000 set
Supply Capability:3000 set/month
Specifications:
Size: 1/4 "-3 "
Connection: RF/RTJ Flange, Butt Welded
Pressure Rating: Class 150LB~ Class 2500LB
Material: A105,LF2,F11,F5,F22,304,316,304L,316L,Monel.
Structural Features: Bolted bonnet, welded Bonnet, Reduced bore, Full bore
Certification:ISO9001,API600,CE0036
Guarantee: 18months ; OEM offer
Design Standard:
Design & Manufacture Std.: ASME B16.34,BS1873, JIS B2071,B2081
Inspection and Test: API598
Face to Face Dimension: ASME B16.34, BS5352 MSS SP-118
End Flange Dimension: ASME B16.5
Butt-welding End Dimensions to: ASME B 16.25
Threaded End: NPT ANSI B1.20.1, BSP, BSPT,
Socket-weld End: ASME B16.11
