Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:1000 pc
Supply Capability:30000 pc/month
Normal pressure or rating | Class 150-Class 2500,JIS I0K - 20K,PN 10 - PN 420 | |||
Normal diameter or bore | NPS 1/2-40,DN6-1000 | |||
Applicable temperature | －196℃-540℃ | |||
Operation type | Manual,worm gear,pneumatic,electric | |||
Standards and specification
| Design& manufacture
| API6D.API608.ASMEBI6.34,ISO5211,ANSI/AWWAC507,BFCI70-2.MSSSP-72,BS5351,B56364,NACE MR0175
| Connection ends
| ASMEBI6.5,ASMEB16.47.API 605,MSS SP-44,ISO 7005-1,JISB2238,BS12627,ASMEBI6.25,ASMEB16.11,BS 12760 |
Face to face dimension | ASMEB16.10,ISO 5752,BS 558, BS12982
| Testing &inspection | API598,API6D,API607,API6FA,BS6755.BS12569,MSS SP-82,MSS SP-6I | |
Reliable seat seal
The structure design of elastic sealing ring has been adopted for floating ball valves. This seat design features a bigger sealing pressure ratio between the ring surface and the ball when medium pressure gets lower, where the contacting area is smaller. Thus, the reliable seal is ensured. When the medium pressure gets higher, the contacting area between seat ring and ball becomes bigger as the sealing ring transforms elastically to undertake the bigger force 5 pushed by the medium without any damage.
Fire safe design
With the valve heated in a fire application, the non-metal material parts such as seat sealing ring of PTFE, stem back seat gasket, gland packing, and the sealing gasket between body and bonnet might disintegrate or be damaged due to high temperature. Specially designed structure of auxiliary metal to metal seal is provided to effectively prevent both internal and external leakage of the valve. As required by customers, floating ball valves with fire safe design can meet the requirement of API 607, API 6FA, BS6755 and B/T 6899
Reliable stem seal
The blow-out proof design has been adopted for the stem to ensure that even if the pressure in the body cavity is risen accidently and the packing flange becomes invalid, the stem may not be blown out by medium. The stem features the design with a backseat, being assembled from underneath. The sealing force against the backseat gets higher as the medium pressure becomes higher. So the reliable seal of the stem can be assured under variable medium pressure
Anti-static feature
The traditional packing flange design has been improved to be of two piece structure, i.e., being as a packing flange plate and a follower, the latter contacts the flange plate with spherical surface. Thus, the follower remains vertical always, and is lined internally with a PTFE bush to prevent the galling against and friction between the stem, which can also reduce the operation torque of the valve.
The traditional packing flange design has been improved to be of two piece structure, i.e., being as a gland flange and gland, the latter contacts the gland flange with spherical surface. Thus, the gland remains vertical always, and is lined internally with a PTFE bush to prevent the galling against and friction between the stem, which can also reduce the operation torque of the valve.
